Cyclic Tests and Simulations of Spatial RC Frame-Shear Wall Structures

Abstract:

The cyclic tests of three one-storey spatial RC frame-shear wall structures with slabs were conducted to investigate the failure modes and the base shear-floor displacement hysteretic responses of the model structures. Then three dimensional numerical simulations were performed using the finite element program ABAQUS/Standard and ABAQUS/Explicit. The test results are detailed in this paper and compared to those of the numerical simulations. It is shown that: (a) plastic hinges initiated at the bottom of the shear wall and followed by forming near the upper ends of columns, resulting in wall-column hinges side-sway failure mechanism; (b) to a certain extent, the horizontal force bearing capacity of the structure increases with the increasing of the vertical load; (c) it is verified that the pushover results of both ABAQUS/Standard and ABAQUS/Explicit solutions agree well with the test results in the case that the parameters are reasonably chosen.

• Periodical: Advanced Materials Research (Volumes 163-167)
• Pages: 1569-1573
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.163-167.1569
• Online since: December 2010
• Authors: Shi Xiang Huang, Xin Yu Zhao
• Keywords: Cyclic Test, Frame-Shear Wall Structure, Numerical Simulation, Reinforced Concrete (RC)

References

[1] S. H. Ju and M. C. Lin. Journal of Structural Engineering. Vol. 125(1999), P. 25.

[2] Y. Lu. Earthquake Engineering and Structural Dynamics. Vol. 31(2002), P. 79.

[3] Z. F. Chen and D. J. Ding. Journal of Southeast University. Vol. 24(1994), P. 47 [in Chinese].

[4] Z. M. Xiong and Q. X. Shi. Journal of Building Structures. Vol. 27(2006), P. 89 [in Chinese].

[5] Concrete Code of China. Code for Design of Concrete Structures (GB50010-2002). Publishing House of Building Industry in China, Beijing, China, 2002, P. 192.

[6] Abaqus Inc. Abaqus User Manual, Version 6. 7, (2007).
