Calculation and Analysis of the Deflections of U-Section Steel-Encased Concrete Composite Beams

Abstract:

U-section steel-encased concrete composite beams is the new type composite beam.This kind of composite beam takes thick steel plate as bottom plate and thinner cold-formed thin-walled steel as web which are connected through a u-shaped section by welding, and then concrete are poured in the u-shaped. In this paper an experimental study was conducted on six full size simple supported U-section steel-encased concrete composite beams.The relationships of the load-deflection curves of the composite beams were obtained. From the experimental results,the variation laws of deflection are analysed,and three defletion formulas are analysed and compared. Based on actual code. A theoretical formula is proposed for defletion. The results of theoretical formula are proved to be in good agreement with the experimental results.

• Periodical: Advanced Materials Research (Volumes 163-167)
• Pages: 846-853
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.163-167.846
• Online since: December 2010
• Authors: Xue Jun Zhou, Ting Zhang, Yuan Zhi Zhang
• Keywords: Analysis of the Deflection, Calculation of the Deflection, Compared, Steel-Encased Concrete Composite Beam, U-Section
