A Study on Stability of Expressway Tunnel Surrounding Rock Containing Weak Intercalated Rock

Abstract:

Weak intercalated rock plays an important role in the stability of engineering rock mass. It controls the mechanism of deformation and breakage of rocks. Systematic numerical tests have been carried out to study the stability of surrounding rock mass with different distributions of weak intercalated rock has been analyzed by the FEM software ABAQUS. All of the numerical modelings are plain-strain type with elasto-plastic constitutive law and Drucker-Prager failure criterion. Some quantificational results about the influence of weak intercalated rock are summarized, especially the influence on the deformation, stress of surrounding rocks and plastic zone. Because of weak intercalated rock, the stress of surrounding rock appears the character of discontinuity. In addition, the distribution of plastic zone is also affected. When weak intercalated rocks exist in vault, spandrel and bottom, the situation of surrounding rock is comparatively unfavorable. These results have a certain role in guiding significance to the site selection and layout, the majorization of supporting system and the construction of tunnel of the same kind.

• Periodical: Advanced Materials Research (Volumes 168-170)
• Pages: 2543-2547
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.168-170.2543
• Online since: December 2010
• Authors: Da Kun Shi, Yang Song Zhang
• Keywords: Numerical Simulation, Rock Tunnel, Stability of Surrounding Rock, Weak Intercalated Rock

References

[1] Liu Y R and Tang H M. Mechanics of Rock Mass[M]. Beijing: Chemical Industry Press, 2008, 12 (In Chinese).

[2] Zhang Y X. Mechanics of Rock[M]. Beijing: China Architecture & Building Press, 2008 (In Chinese).

[3] GUO Fu-li, ZHANG Ding-li and SU Jie, etc. Research on deformation mechanism about stratified tunnel surrounding rock mass containing weak intercalation [J]. Rock and Soil Mechanics, 2008, (11): 247-252 (In Chinese).

[4] Bruneau G, Hadjigeorgiou D B, Tylerb J and Potvin Y. Influence of faulting on a mine shaft-a case study: part I-Background and instrumentation[J]. InternationalJournal of Rock Mechanics&Mining Sciences, 2003, (40): 95-111.

DOI: 10.1016/s1365-1609(02)00115-6

[5] Kwon S and Wilson J W. Deformation mechanism of the underground excavations at the WIPP site[J]. Rock Mech. Rock Eng., 1999, 32(2): 101-122.

DOI: 10.1007/s006030050027

[6] Zhang Z Q. Numerical test on influence of weak interbed on underground tunnel[D]. Xi'an: Xi'an University of Technology(In Chinese).

[7] Jiang J G. Stability of tunnel in jointed surrounding rock under different tectonic stress[J]. Journal of Southwest Jiaotong University, 1982, (1): 20-23 (In Chinese).

[8] Li X P. Effect of joint distributions on stability of underground cavern[J]. Metal Mine, 1997, (3): 10-15 (In Chinese).

[9] Xu G C and Zheng Y R. Research on the yield criterions in rock engineering[J]. Chinese Journal of Geotechnical Engineering, 1990, 12(2): 93-99 (In Chinese).

[10] Shi W M and Zheng Y R. Equivalent Transformation of Mohr-Coulomb Criterion and Its Application in Slope Stability Analysis[J]. Geotechnical Engineering Technique, 2003, (3): 156-161 (In Chinese).

[11] ABAQUS Analysis User's Manual(v6. 9-1).
