Effect of La₂O₃ Additions on Microstructure, Morphology and Pressure Sensing Behaviour of PZT Based Ceramics Sintered in Al₂O₃ Environment

Abstract:

Effect of La2O3 addition on microstructure, morphology and pressure sensing behaviour of (Pb1-x, Lax)(Zr0.52, Ti0.48)O3 based ceramics was studied in three different compositions of La2O3, namely x = 0.10, 0.12 and 0.15. The samples were prepared through a conventional solid-state reaction method using high purity metal oxides powders. In order to control the PbO losses due to high sintering temperature, a novel approach was explored whereby the samples were sintered in Al2O3 environment. Structural investigation using XRD revealed that all samples exhibited a tetragonal crystal structure. However the c/a ratios exhibited a decreasing trend as the La2O3 content increased, indicating that (Pb1-x, Lax)(Zr0.52, Ti0.48)O3 crystals gradually evolved towards pseudocubic structure. SEM micrographs showed that in all samples the grains have uniform pebble stone morphology. The average grain size reduced from ~ 4.5 µm to ~ 3.0 µm with the increment of La¬2O3 content. The performance of pressure sensing behaviour which was investigated using custom-made pressure chamber showed that sample with composition of x = 0.10 exhibited the best piezoelectric properties with high pressure sensitivity, good stability and repeatability.

• Periodical: Advanced Materials Research (Volume 173)
• Pages: 96-101
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.173.96
• Online since: December 2010
• Authors: Mohammad Hafizuddin Haji Jumali, Ying Ying Tio, Ramli Norhashimah, Mat Salleh Muhammad, Muhammad Yahaya
• Keywords: Morphological Analysis, PLZT, Pressure Sensing Behaviour, Solid-State Reaction, Tetragonal Structure

References

[1] L. Pdungsap, N. Udomkan, S. Boonyuen and P. Winotai: Sensors and Actuators Vol. 122 (2005), pp.250-256.

DOI: 10.1016/j.sna.2005.06.002

[2] D.M. Santos, A.Z. Simoes, M.A. Zaghete, C.O. Paiva-Santos, J.A. Varela and E. Longe: Journal of Chemistry and Physics Vol. 103 (2007), pp.371-374.

[3] A. Lozinski: Journal of electroceramics Vol. 19 (2007), pp.303-306.

[4] W-D. Yang: Ceramics International Vol. 27 (2004), pp.373-384.

[5] O.S. Peng, W. Jiang and J.F. Li: Key Engineering Materials Vol. 280-283 (2005), pp.623-626.

[6] L.B. Kong, J. Ma, W. Zhu and O.K. Tan: Journal of Materials Letters Vol. 52 (2002), pp.378-387.

[7] S. Kongtaweelwrt, P. Anuragudum, S. Nualpralaksana, R.B. Heimann and S. Phanichphant: Journal of electroceramics, Vol. 13 (2004), pp.209-214.

[8] S. Tong, S. Ping and W. Chongruo: Vacuum science and technology Vol. 20 (2000), pp.19-20.

[9] S. Dutta, R.N.P. Choudhary and P.K. Sinha: Journal of Alloys and Compounds Vol. 426 (2006), pp.345-351.

[10] Y. Zhang, A.L. Ding, P.S. Qiu, X.Y. He, X.S. Zheng, H.R. Zeng and Q.R. Yin: Journal of Material Science & Engineering B Vol. 99 (2003), pp.360-362.

[11] N.A. Manaf, M.M. Salleh and M. Yahaya: Journal of Advanced Materials Research Vol. 55-57 (2008), pp.253-256.

[12] N. Ramli, M.M. Salleh, M. Yahaya and M.H.J. Jumali: Sains Malaysiana Vol. 38 (2009), pp.685-691.

[13] B. Jaffe, W. R. Cook Jr and H. Jaffe: Piezoelectric Ceramics (Academic Press, London 1971).

[14] Y. Xu: Ferroelectric Materials And Their Applications (Elsevier Science Publishers B. V, North-Holland 1991).
