Effect of Heat Treatment Temperature on Properties of SiO₂-ZrO₂-Al₂O₃-Cr₂O₃ Coatings on Stainless Steel Substrate

Abstract:

The SiO2-ZrO2-Al2O3-Cr2O3 film is coated on the surface of stainless steel using analytical reagent TEOS, ZrOCl2•8H2O, Al(NO3)3•9H2O and Cr(NO3)3•9H2O as precursor and basing on mole ratio to calculate through Sol-gel method. The phase transformation behavior, erosion resistance, thermal shock resistance and abrasion resistance of ceramic coating by different heat treatment are studied. The results show that: 1) The SiO2-ZrO2-Al2O3-Cr2O3 gel coatings has non-crystalline structure after the treatment at 700°C and 800°C. New substance is not created below 700°C. 2) The stainless steel substrate with ceramic coating has a higher erosion resistance at high temperature (700°C and 800°C)than that without coating.3) Thermal shock resistance of the samples treated in 700°C is the best which has reached within 17-21cycles (900°C, air cooling). 4) The stainless steel substrate with ceramic coating has a higher abrasion resistance than that without coating. The samples treated at 700°C and 800°C have the best abrasion resistance.

• Periodical: Advanced Materials Research (Volume 177)
• Pages: 321-324
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.177.321
• Online since: December 2010
• Authors: Shu Xian Liu, Qian Ping Wang, Yi Miao Nie
• Keywords: Heat Treatment Temperature, Property Analysis, SiO₂-ZrO₂-Al₂O₃-Cr₂O₃ Film, Stainless Steel (SS)

References

[1] Q. P Wang, J.S. Zhang, Z.H. Huang, et al.: Refractories Vol. 39 (2005), p.452.

[2] S.X. Liu, L.R. Yang and Z.H. Huang: Refractories. Vol. 41(2007), p.118 Fig. 4 SEM of Photograph of interface.
