Multi-Dimensional Vibrating Screen Design and Motion Analysis

Abstract:

a kind of multidimensional vibrating screen has been developed by the author in order to improve the screening efficiency of material. The paper introduces the structure composition and functional properties of multidimensional vibrating screen. The structural performance parameters such as degree of freedom, virtual constraint and coupling degree of the main mechanism have been calculated. And the motion performance of the multidimensional vibrating screen has been analyzed. Meanwhile the kinematics equation is established. This kind of multidimensional vibrating screen not only has concise structure and better symmetry and decoupling performance, but also improve the dispersion and leaking screen effect obviously compared with traditional vibrating screen.

• Periodical: Advanced Materials Research (Volumes 201-203)
• Pages: 1672-1677
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.201-203.1672
• Online since: February 2011
• Authors: Cheng Jun Wang, Lv Zhong Ma, Yao Ming Li
• Keywords: Kinematics, Multidimensional Vibrating Screen, Parallel Mechanism, Structure Design

References

[1] Zitong Chen, gan Sun. The prospects about large-scale screening machinery of the moist fine coal[J]. Coal Processing and Utilization, 1999(6) P: 4-6.

[2] Banchun Wen, yinong Li, yiming Zhang and so on. Vibration utilization engineering[M]. Beijing: Science Press, (2005).

[3] Huiping Shen, huifang Zhang, jiangtao Zhang and so on . The law of motion about screening and the study about the track of the vibrating screen in parallel movement[J]. Mechanical Design, 2008, 25 (12) P: 21-23.

[4] Tingli Yang. Topology learning robot [M]. Beijing: Mechanical Industry Press, (2004).
