Parameter Optimization and System Design of the Welding Power Supply for Resistance-Butt Welding of Nuclear Fuel Rod

Abstract:

This paper firstly gives a brief description about the principle of resistance-butt welding of nuclear fuel rod, and it points out that the power supply is a key technology for welding process. According to the welding process and the welded material properties, capacitor discharge power supply is devised as welding power supply. The design of charging circuit of single-phase bridge rectifier with SCR and control circuit is finished. The process of power discharge is simulated and the parameters (capacitance C, charging voltage u_c) are optimized with Matlab. By the welding experiments, it shows that the output current curve is suitable for resistance-butt welding of nuclear fuel rods, and the test results of welding samples entirely consistent with process requirements.

• Periodical: Advanced Materials Research (Volumes 201-203)
• Pages: 2661-2666
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.201-203.2661
• Online since: February 2011
• Authors: Fang Quan Chen, Zu Wei Lin, Guo Wei Liang
• Keywords: Charging Circuit, Discharge Process, Parameter Optimization, Resistance-Butt Welding, Welding Power Supply

References

[1] Chen Fangquan, Liang Guowei, Lin Zuwei, Guo Xulin, Yang Tonggao, Liu Shenggang. Welding Technology, Vol. 39 (1) (2010), pp.16-19. (in Chinese).

[2] Lin Zuwei, Chen Fangquan, Liang Guowei, Guo Xulin, Yang Tonggao. Journal of Shanghai University (Natural Science Edition), Vol. 16 (2) (2010), pp.147-151. (in Chinese).

[3] Liang Guowei. Research on Welding Process and Key Technology of Resistance-butt Welding of Zr Tube Used in Nuclear Power. Master thesis. Shanghai: Shanghai University, 2010. 3. (in Chinese).

[4] Zhang Hongbing, Huang Shisheng, Zhou Yiqing. CHINA WELDING, Vol. 16 (3) (2007): pp.1-5.

[5] Wang Zhenyu. Circuit analysis. Beijing: Science Press, 2006. (in Chinese).

[6] Liu Bo, Tong Shenxiu, Wu Ping. Nuclear Power Engineering, Vol. 23 (5) (2002): pp.70-74. (in Chinese).

[7] Wang Ming, Cheng Xuanting, Yu Zhen. Electric Welding Machine, Vol. 31(8) (2001), pp.29-30, 37. (in Chinese).

[8] Liu Mingyu. Journal of Chongqing University (Natural Science Edition), Vol. 20(3) (1997), pp.26-31. (in Chinese).

[9] Zhang Ying, Gan Zhengjia, Jin Weixiang. Journal of Changsha University of Electric Power (Natural Science Edition), Vol. 17(3) (2002), pp.44-47. (in Chinese).

[10] Wang Zhenming, Xue Jiaxiang, Wang Fuguang. CHINA WELDING, Vol. 16 (4) (2007), pp.1-6.
