Fault Diagnosis System for Large-Scale Equipments Based on Hybrid Reasoning

Abstract:

Because of their complex structures, diverse functions, and cross-correlation among subsystems, the fault of large-scale equipments occurs easily, but its trouble shooting is difficult. Firstly, a hybrid reasoning method is proposed, and the framework of fault diagnosis system is constructed according to characteristics of case based reasoning (CBR) and rule based reasoning (RBR). Secondly, CBR and RBR applied to fault diagnosis for large-scale NC equipments are analyzed. In RBR process, the fault tree was obtained by reachability matrix, and the rules knowledge is automatically generated by fault tree, so the bottleneck of acquiring rules knowledge is solved. Lastly, this method is used in the fault diagnosis of certain large-scale NC equipment, which verifies the validity of the method.

• Periodical: Advanced Materials Research (Volumes 201-203)
• Pages: 956-961
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.201-203.956
• Online since: February 2011
• Authors: Ming Chen, Rui Zhang, Ying Lei Li
• Keywords: CBR, Fault Diagnosis, Fault Tree, RBR, Reachability Matrix

References

[1] Zhiwei Ni, Xuejun Li, Caiping Hu and Fenggang Li: Mini-micro system. Vol. 7 (2004), p.1155 (In Chinese).

[2] Zhenlin Ma, Yingjie Yu: Microcomputer information. Vol. 4(2010), p.111 (In Chinese).

[3] Zhiyue Bi, Dayong Luo: Agricultural equipment and vehicle engineering. Vol. 9(2007), p.31 (In Chinese).

[4] Yifei Yang, Yuanxin Qu: Journal of spacecraft TT&C technology. Vol. 3(2005), p.27 (In Chinese).

[5] Yuan-Hsin Tung, Shian-Shyong Tseng, Jui-Feng Weng, Tsung-Ping Lee, Anthony Y.H. Liao and Wen-Nung Tsai: Expert systems with applications. Vol. 37(2010), p.2427.

[6] Y-T Tsai: Proceedings of the institution of mechanical engineers, part C: journal of mechanical engineering science. Vol. 223(2009), p.2431.

[7] Pang Shen Yee, Loo Chu Kiong, Lim Way Soong, Adaptive case based reasoning for fault diagnosis, in SOCPAR 2009-soft computing and pattern recognition, pp.678-681, (2009).

DOI: 10.1109/socpar.2009.135

[8] Information on http: /www. wikipedia. org.

[9] Pei Zheng, Research on case-based reasoning for fault diagnosis", Huazhong university of science and technology, 2008(In Chinese).

[10] Yan Zhou, Research and development of automatic fault tree synthesis system, Dalian university of technology, 2005(In Chinese).

[11] Junzhe Duan, Huacong Li: Science technology and engineering. Vol. 7(2009), p.1914 (In Chinese).
