Experimental and Numerical Investigation of the Steel X210Cr12 Forming in Semi-Solid State

Abstract:

Semi-solid forming processes belong to the progressive technologies which can be exploited for the manufacturing products with complicated shapes and special material and utility properties. Semi-solid metal forming takes place at temperatures between solidus and liquidus combining the advantages of metal forging and metal casting processes. The paper is focused on the analysis of microstructures and phase composition of the X210Cr12 steel identified in the thin-walled products after forming in semi-solid state. Microstructure of the X210Cr12 steel after rapid cooling and solidification from semi-solid state is formed by quasi-globular grains of metastable austenite surrounded by carbides and fine eutectics. The fraction of metastable austenite in structure was found to be 96 % exhibiting the thermal stability up to the temperature of 500 °C. Along with experimental study, the numerical analysis of the material flow during a die cavity filling was carried out using developed 2D simulation model taking into account one-phase non-newtonian flow.

• Periodical: Advanced Materials Research (Volume 214)
• Pages: 461-466
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.214.461
• Online since: February 2011
• Authors: Mária Behúlová, David Aišman, Hana Jirková, Bohuslav Mašek
• Keywords: Die Cavity Filling, Microstructural Analysis, Numerical Simulation, Phase Composition, Semi-Solid State, X210Cr12 Steel

References

[1] M. C. Flemings: Metallurgical Science and Technology Vol. 18 No. 2 (2000) p.1.

[2] M. Kiuchi, R. Kopp: CIRP Annals - Manufacturing Technology Vol. 51 Issue 2 (2002) p.653.

[3] B. Hallstedt, E. Balithev, H. Shimahara, D. Neuschutz: ISIJ International, Vol. 46 No. 12 (2006) p.1852.

[4] G. Hirt, R. Kopp: Thixoforming. (WILEY-VCH Verlag GmbH & Co. KGaA, Weinheim 2009).

[5] W. Püttgen, W. Bleck, G. Hirt, H. Shimara: Advanced Enginnering Materials, 9, No. 4 (2007), p.231.

[6] W. Püttgen, B. Hallstedt, W. Bleck, P. J. Uggowitzer: Acta Materialia Vol. 55 Issue 3 (2007), p.1033.

DOI: 10.1016/j.actamat.2006.09.021

[7] G. Hirt, G. et al.: CIRP Annals - Manufacturing Technology Vol. 54 Issue 1 (2005) p.257.

[8] H. V. Atkinson: Modelling of semi-solid processing (Aachen, Shaker 2008).

[9] Staňková, H. et al.: Influence of Thixoforming on Structure Development of the Tool Steel. In.: 12th International Research/Expert Conference – TMT 2008, Turkey.

[10] Ronešová, B. Mašek: U.S. Patent 7, 480, 155 (2009).

[11] M. Behúlová: Aerospace Sciences & Aviation Technology Vol. 1 (2009) p.1.

[12] D. Aišman, H. Jirková, B. Mašek, in: Proceedings of the 20th International DAAAM Symposium Vol. 20 No. 1 (2009) p.1895.

[13] H. Jirková, D. Aišman, B. Mašek: Journal of Alloys and Compounds Vol. 504 (2010) p. S500.

[14] B. Mašek, D. Aišman, M. Behúlová, H. Jirková: Transactions of Nonferrous Metals Society of China. Vol. 20 (2010), p.1037.

[15] P. Grgač, R. Moravčík, M. Kusý, I. Tóth, M. Miglierini, E. Illeková: Materials Science and Engineering A Vol. 375-377 (2004), p.581.

[16] ANSYS Theoretical Manual, Release 10. 0, SAS IP, Inc., (2005).
