The Method of Fault Feature Extraction from Acoustic Emission Signals Using Wigner-Ville Distribution

Abstract:

Wigner-Ville distribution (WVD) has the characteristics of very high-energy accumulation and excellent time-frequency resolution. It is a good way to extract fault feature of acoustic emission (AE) signals due to mechanical component broken. The characteristics of typical AE signals initiated by damages are analyzed. Based on the extracting principle of AE signals from damaged components, the WVD analysis method of AE signal is developed. WVD method is employed to the fault diagnosis of rolling bearings with AE technique. The fault features reading from experimental data analysis are clear, accurate and intuitionistic, meantime, the validity and accuracy of WVD method proposed are nice from the experimental results. Therefore, WVD method is useful for condition monitoring and fault diagnosis in conjunction with AE technique.

• Periodical: Advanced Materials Research (Volume 216)
• Pages: 732-737
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.216.732
• Online since: March 2011
• Authors: G.F. Bin, C.J. Liao, Xue Jun Li
• Keywords: Acoustic Emission (AE) Signal, Fault Feature Extraction, Rolling Bearing, Wigner-Ville Distribution (WVD)

References

[1] G.T. Shen, G. Dai, S.F. Liu, Acoustic emission testing progress in china, Nondestructive Testing, 2003, 25 (6), 302-307.

[2] Yuji Ohue, Akira Yoshida, New evaluation method on gear dynamics using continuous and discrete wavelet transforms, Journal of Vibration and Acoustics, 2003, 125(7): 274-281.

DOI: 10.1115/1.1547465

[3] C.W. Lee, Y.S. Han, The directional Wigner distribution and its application, Journal of Sound and Vibration, 1998, 216(4): 585-600.

DOI: 10.1006/jsvi.1998.1715

[4] J.K. Hammond, P.R. White, The Analysis of non-stationary signals using time-frequency methods, Journal of Sound and Vibration, (1996) 190(3), 419-447.

DOI: 10.1006/jsvi.1996.0072

[5] X.D. Zhang, Modern signal processing, Beijing: Qinghua University Press, 1995, pp.462-463.

[6] Z.R. Struzik, Wavelet methods in (financial) time-series processing, Physical A: Statistical Mechanics and its Application, 296 (1-2) (2001) 307-319.

DOI: 10.1016/s0378-4371(01)00101-7

[7] C.H. Jiang, L.S. Wang, W. You, et al, Research on acoustic emission signal de-noising based on translation invariant wavelet, Chinese Journal of Scientific Instrument, 27 (6) (2006), 607-610.

[8] Q. Wang, F. Chu, Experimental determination of the rubbing location by means of acoustic emission and wavelet transform, Journal of Sound and vibration, (2001) 248(1), 91-103.

DOI: 10.1006/jsvi.2001.3676

[9] H.B. Mei, Rolling bearing vibration monitoring and diagnosis, Beijing: Mechanical Engineering Press 1996 pp.8-9.
