Experimental Study on Melting Characteristics of Spherical Capsule Packed Bed Latent Heat Storage Material System

Abstract:

A laboratory equipped with the thermal energy storage unit utilizing the solar heat sources was designed and constructed. The spherical capsules which were filled with the phase change material (PCM) were installed inside the unit. The temperatures at inlet and outlet of the thermal energy storage (TES) unit and at the first through seventh layers of heat transfer fluid (HTF) were measured. Many groups of experimental schemes were designed to evaluate the storage unit’s performance. The effects of inlet fluid temperature and flow rate of HTF on the performance of the storage unit were analyzed. The experimental results showed that, with the inlet temperature and flow rate of HTF increasing, the time required to complete the charge process reduced constantly; the efficiency of thermal energy storage is consequently improved. The results provide the basis for designing, optimizing, and applying the TES unit.

• Periodical: Advanced Materials Research (Volumes 217-218)
• Pages: 1525-1530
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.217-218.1525
• Online since: March 2011
• Authors: Hai Ting Cui
• Keywords: Charging Performance, Heat Transfer Fluid, Phase Change Materials (PCM), Thermal Energy Storage Unit

References

[1] Ahmet, Koca., Hakan, F., Oztop, Tansel. Koyun. Energy and exergy analysis of a latent heat storage system with phase change material for a solar collector. Renewable Energy Vol. 34(2008), p.567.

DOI: 10.1016/j.renene.2007.03.012

[2] Bansal, N.K., Buddhi, D. Performance equations of a collector cum storage system using phase change materials. Sol Energy Vol 48(1992), p.185.

DOI: 10.1016/0038-092x(92)90137-y

[3] Chen, S.L., Yue, JS. Thermal performance of cool storage in packed capsules for air-conditioning. Heat Recovery Syst CHP Vol 11(1991)p.551.

DOI: 10.1016/0890-4332(91)90057-b

[4] Keumnam, Cho., Choi,S.,H. Thermal characteristics of paraffin in a spherical capsule during freezing and melting processes. International Journal of Heat and Mass Transfer Vol 43(2000), p.3183.

DOI: 10.1016/s0017-9310(99)00329-4

[5] Murat, Kenisarin., Khamid, Mahkamov. Solar energy storage using phase change materials. Renewable Energy Vol 9(2007), p. (1913).

DOI: 10.1016/j.rser.2006.05.005

[6] N, Nallusamy., S, Sampath., R, Velraj., 2007. Experimental investigation on a combined sensible and heat latent storage system integrated with constant/varying heat sources. Renewable Energy Vol 32(2007), p.1206.

DOI: 10.1016/j.renene.2006.04.015

[7] Sharma, A., Tyagi, V.V., Chen, C.R. Review on thermal energy storage with phase change materials and applications. Renew Sust Energy Rev Vol 13(2009), p.318.

[8] Yagi, J., Akiyama, P., Storage of thermal energy for effective use of waste heat from industries. J Mater Process Technol Vol 48(1995), p, 793.

DOI: 10.1016/0924-0136(94)01723-e
