Improvement in Ovality of Pipeline Steel X80 with Weld Power under Multi-Wire SAW Welding Process

Abstract:

Pipeline steel X80 is a kind of advanced high grade steel and commonly used in long-distance transportation of oil and gas. Ovality of the pipe plays key role in improving its crushing strength. In this paper, a simulation method is proposed to improve the performance of ovality of X80 Pipeline Steel. First, a 3D thermo-mechanical coupled finite element model of the multi-wire SAW welding processes is built using MSC.MARC, upon which parameters of double ellipsoid heat source model is determined. Then, the relationship between weld power and ovality is studied under difference process inputs and a satisfactory weld power is found to decrease the ovality of the pipeline steel. Finally, validation and prediction of deformation and ovality of the pipeline is carried out via plate welding experiments.

• Periodical: Advanced Materials Research (Volumes 239-242)
• Pages: 1823-1831
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.239-242.1823
• Online since: May 2011
• Authors: Yi Bo Li, Ming Hui Huang, Xin Jiang Lu
• Keywords: Multi Wire Saw, Ovality, Pipeline Steel X80, Weld Power

References

[1] HUANG Ke-jian, LIU Jin-lei, RUAN Fen. Application of UOE forming technology for the large longitudinal seam arc welding steel pipes. Forging technology., 2006,1:18-21

[2] A. Yaghi, T.H. Hyde, A.A. Becker, W. Sun1,J.A. Williams2, and B. Pathiraj. Simulation Of Residual Stresses In Welded P91 Pipes. 5th International Conference on Mechanics and Materials in Design, Chapter IV: Welds at High Temperature (WELDON) in Design.2006:1-15

[3] Document of Marc 2010, Volume A: Theory and User Information, MSC.Software, Santa Ana,(2010)

[4] MA Bo, PENG Yan, LIU Yun-fei, JIA Bin. Constitutive relationship of hot deformation of X80 pipeline steel. Mechanic Automation and Control Engineering (MACE), 2010 International Conference on, 2010:3875 – 3878

DOI: 10.1109/mace.2010.5535389

[5] LI Ya-juan, Li Wu-shen. Numerical simulation of temperature field for X80 pipeline welding. Welding technology, 2010, 39(1):pp.8-11

[6] H.Purmohamad, A.Kermanpur, and M.Shamanian. Numerical Simulation and Experimental Investigation of Residual Stresses in the Circumferential Butt GTAWof Incoloy 800H Pipes. Journal of Materials Engineering and Performance,2010,19(1):13-21

DOI: 10.1007/s11665-009-9391-0

[7] Goldak J.A new finite model for welding heat source .MetallurgicalTransactions,1984,5B(2)：299-305.

[8] Rosenthal D. Mathematical theory of heat distribution during welding and cutting. Weld. J. , 1947,20(5): pp.220-234
