Influence Analysis of Different Prestress Stretching Order to Rectangle Aqueduct

Abstract:

Large finite element software is used to analyze Shuangji River rectangle aqueduct in the South-to-North Water Transfer Project. The stress and displacement of the whole structure are obtained under different stretching order of prestress during the aqueduct construction period. Calculation results show that, from the point of stress, the better prestress stretching order is stretching longitudinal first, then the transverse and finally vertical; from the point of displacement, drawing order variation has little influence on displacements in the stretching process; it is a relatively good simulation method to add a steel plate to the area where the prestressed strands are acted on. In this way, the real anchor state can be simulated, and the local stress concentration can be reduced.

• Periodical: Advanced Materials Research (Volumes 255-260)
• Pages: 1138-1141
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.255-260.1138
• Online since: May 2011
• Authors: Ze Yu Wu, Xin Li Bai, Yu He Li
• Keywords: Finite Element Analysis (FEA), Pre-Stress, Rectangle Aqueduct, Stretching Order

References

[1] B. Qian: Design Specification of Hydraulic Building-DL5077-1997 (China Power Press, 1997)

[2] S.L. Wang and W.X. Hao: Journal of Hebei Agricultural University, Vol. 22(2002) p.152

[3] Y. Zhao and X.L. Bai: Journal of Irrigation and Drainage, Vol. 21(2002), p.53

[4] X. L. Bai, at el: Journal of North China University of Water Resources and Electric Power, Vol. 28(2007), p.216 (in Chinese)
