Research on Deflection and Stress of CRCP under Concentrated Vehicle Load over Hollow Base

Abstract:

Based on the small deflection theory of elastic thin plate and the equivalence principle of deflection and stress, the concentrated vehicle load which acts on the CRCP is translated into the equivalent half-wave sine load by Fourier transform. On the basis of this transform, the deflection and stress formulas are put forward when CRCP is subjected to a concentrated vehicle load with hollow foundation. The following results are obtained from the analysis. The maximal deflection is proportional to the concentrated vehicle load and slab width, and inversely proportional to the lateral bending stiffness and slab thickness. The slab width and thickness have a significant influence on the maximal deflection. The maximal stress is proportional to the concentrated vehicle load and slab width as well as inversely proportional to the slab thickness. The influence of slab thickness is significant to the maximal stress. In conclusion, increasing the slab thickness is the preferential choice to reduce the maximal deflection and stress.

• Periodical: Advanced Materials Research (Volumes 255-260)
• Pages: 1800-1805
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.255-260.1800
• Online since: May 2011
• Authors: Xiao Bing Chen, Xiao Ming Huang, Jin Hu Tong
• Keywords: Concentrated Vehicle Load, Deflection Formula, Equivalence Principle, Half-Wave Sine Load, Stress Formula, Thin Slab over Hollow Base

References

[1] X.J. Deng, X.M. Huang, in: Principle and Method in Design of Highway Pavement, edited by X. Liang, volume 7 of Design Method of Rigid pavement, chapter, 12, China Communications Publishers, Beijing, China (2001), pp.367-368.

[2] W. Huang, Z.D. Qian, in: Theory and Methodology of High-Class Concrete Pavement Design, volume 1 of Design of Continuously Reinforced Concrete Pavement, chapter, 4, China Communications Publishers, Beijing, China (2000), pp.206-212.

[3] O.I. Selezneva, C. Rao, M.Darter et al.: Development of a Mechanistic-Empirical Structural design Procedure for Continuously Reinforced Concrete Pavements, Trb. Forum (2004), pp.375-399.

DOI: 10.3141/1896-05

[4] D.G. Zollinger, N. Buch, D. Xin et al, in: Performance of Volume VI-Continuously Reinforced Concrete Pavement Design, Construction and Performance. Final report, FHWA-RD-98-102, PCS/Law Engineering (1999).

[5] O.I. Selezneva, M.I. Darter, D.G. Zollinger et al.: Characterization of Transverse Cracking Spatial Variability: Using of LTPP Data for CRCP Design, Trb. Forum (2003), pp.147-155.

[6] National Cooperative Highway Research Program, in: Guide for Mechanistic-Empirical Design of New and Rehabilitated Pavement Structures, Report, NCHRP1-37A, USA(2004), pp.107-133.

[7] Ministry of Communications, in: Specification of Cement Concrete Pavement Design for Highway(JTG D40-2002), China Communication Press, Beijing, China (2003).

[8] X.Y. Gu, Q. Dong and F.J. Ni: Research on Crack Progression of Continuously Reinforced Concrete Pavement, Journal of Highway and Transportation Research and Development, Vol. 6 (2007), pp.37-40.

[9] X.Y. Wang, J.Y. Xiao, Y.Z. Tang et al, in: Mechanics Analysis and Design of Composites, edited by Q. Luo, volume 4 of Micromechanics of Composite Materials, chapter, 4, National University of Defense Technology Press, Changsha, China (1999), pp.100-118.

[10] Department of Mathematics of Tongji University, in: Higher Mathematics(Volume II), edited by S. Guo, volume 7 of Fourier Series, chapter, 11, Higher Education Press, Beijing, China (1996), pp.293-309.

[11] Department of Mathematics of Tongji University, in: Higher Mathematics(Volume I), edited by S. Guo, volume 5 of Higher Order Derivatives, chapter, 2, Higher Education Press, Beijing, China (1996), p.124.

[12] Z.L. Xu, in: Mechanics of Elasticity, volume 6 of Basic Theory of Plan Problem, chapter, 2, Higher Education Press, Beijing, China (1960), pp.25-29.

[13] X.F. Xun, X.S. Fang and T.L. Guan, in: Mechanics of Materials, edited by X. Wu, volume 5 of Bending Stress, chapter, 4, Higher Education Press, Beijing, China (1994), pp.188-192, 436-441.
