Numerical Simulation of Characteristics of Sudden Reduction Tube Flow Based on FLUENT

Abstract:

Sudden reduction tube was always used in spillway tunnel, drainage pipes and so on. The energy loss coefficient of sudden reduction tube flows is an important index of sudden reduction tube. In the present paper, this coefficient and relative parameters, such as the contraction ratio and Reynolds number of the flow through sudden reduction tube, were analyzed by theoretical considerations, and their relationships were obtained by the numerical simulations. It could be concluded that the energy loss coefficient was mainly dominated by the contraction ratio. The less the contraction ratio is, the larger is the energy loss coefficient. When Reynolds number is more than 10⁵, Reynolds number has little impact on it. An empirical expression, which was verified by comparison with other experiment data, was presented to calculate the energy loss coefficient of sudden reduction tube flows.

• Periodical: Advanced Materials Research (Volumes 255-260)
• Pages: 3461-3465
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.255-260.3461
• Online since: May 2011
• Authors: Wan Zheng Ai, Bai Gang Huang
• Keywords: Backflow Region Length, Energy Loss Coefficient, Fluent, Numerical Simulation, Sudden Reduction Tube Flows

References

[1] Bullen, P.R., Cheeseman, D.J., Hussain, L.A., Ruffellt, A.E.. The determination of pipe contraction pressure loss coefficients for incompressible turbulent flow. Journal of Heat and Fluid Flow. 1987, 8(2), 111-118.

DOI: 10.1016/0142-727x(87)90008-7

[2] Wang, D.C., Yue, P.J.. An experimental studies on energy dissipation of orifice plate in the tube. Journal of Hydrodynamics, Ser.A. 2(3), 1987,41-50. (in Chinese)

[3] Li, J.X., Zhao Z.X.. Hydraulics. Hohai university publish house. 1987.

[4] Yang, Y.Q., Zhao, H.H.. Numerical simulation of turbulent flows passed through an orifice energy dissipator within a flood discharge tunnel. Journal of Hydrodynamics, Ser.B. 1992,4(3), 27-33.

[5] Xia, Q.F., Ni, H.G.. Numerical simulation of plug energy dissipator. Journal of Hydraulic Engineering. 2003,(8), 37-42. (in Chinese)

[6] Liu, S.J., Yang, Y.Q., Xu, W.L., Wang, W.. Hydraulic characteristics of throat-type energy dissipater in discharge tunnels. Journal of hydraulic engineering. 2002,(7):42-46.
