Stress Characteristics Analysis of a Corrugated Web Composite Girder under Out-Plane Bending

Abstract:

The focus of this study is to analyse the stress distribution of corrugated web girder subjected to out-plane bending. Welded joining is considered in this study to connect the corrugated web and beam flange. As stress concentration is very critical for the prediction of fatigue life of the structure, this study provides preliminary results for further fatigue assessment of box-section girder bridge with such structural details. A finite element analysis based study has been conducted to trace the stress distribution along the corrugated web with varying thickness and cope hole details. The comparison with related simplified expression and typical stress concentration behaviours are outlined in this paper. Comments are given for the further consideration of presented stress characteristics in the fatigue design.

• Periodical: Advanced Materials Research (Volumes 255-260)
• Pages: 714-717
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.255-260.714
• Online since: May 2011
• Authors: Z.Y. Wang, Qingyuan Wang, L.F. Tan, Y.Y. Chen, R.J. Jiang
• Keywords: Finite Element, Out-Plane Bending, Steel Corrugated Web Girder, Stress Concentration

References

[1] Wang ZY, Wang QY, Chen YY, Shi XS, Ouyang WX: J Highway and Transportation Res, Vol 6(2010), pp.64-71

[2] Miki C in: Pro, Bridge Maintenance, safety, Management and Cost-Watanabe. Tokyo: Tokyo Institute of Technology, 2004, pp.11-19.

[3] Nakasu K, Yoda T, Sato K: J. Struct Eng, JSCE,Vol 647 (2000), pp.267-279.

[4] Sugimoto I, Murata K, Nishida H: Quarterly Report of RTRI, Vol 44(2003), pp.142-146

[5] Wang ZY, Ouyang WX, Wang QY, Chen YY, Jiang RJ: Key Eng. Mater, Vol 452-453 (2011), pp.353-356

[6] ANSYS@Academic Research, Release 12.1, Help System, Structural Analysis Guide, ANSYS, Inc., (2010)
