A New Rigid Plastic Messless Method for Simulation of Bulk Metal Forming Processes

Abstract:

In this paper a rigid plastic mesh free method for slightly compressible materials is presented for the simulation of bulk metal forming processes. In this model MLS shape functions are used for the approximation of velocity field. These shape functions are defined in initial coordinates of particles. By using this method the support of shape functions covers the same set of particles during material deformation. Transformation method is used for imposition of essential boundary conditions. Transformation matrix is formed only once at the initial stage, because shape functions are defined in initial coordinates system. For evaluation of the presented model, disk upsetting and ring upsetting processes are simulated. Results obtained from this model are compared with experimental data and FEM results and good agreement is observed between them.

• Periodical: Advanced Materials Research (Volumes 264-265)
• Pages: 1-5
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.264-265.1
• Online since: June 2011
• Authors: M. Foroutan, M. Mortazavi
• Keywords: Meshless, Metal Forming, Ring Compression, Upsetting

References

[1] T. Beytschko, Y.Y. Lu and L. Gu : Int. Journal. Numer. Methods Engrg. Vol. 37 (1994), p.229.

[2] .Y. Lu, T. Beytschko and L. Gu: Comput. Methods Appl. Mech. Engrg. Vol. 113 (1994), p.397.

[3] P. Lancaster, K. Salkauskas: Math. Comput. Vol. 37 (1981), p.141.

[4] Y.M. Guo, K. Nakanishi: J. Material processing Technology Vol. 140 (2003), p.19.

[5] Y.M. Guo, K: Advances in Engineering software Vol. 36 (2005), p.234.

[6] S. Xiong, J.M.C. Rodrigues and P.A.F. Martins: Computers and structures Vol. 83 (2005), p.574.

[7] Y.H. Liu, J. Chen , S. Yu and X.W. Chen: Acta Metall. Sin(Engl. Lett). Vol. 19 (2006), p.371.

[8] C.S. Li, X.H. Liu and G.D. Wang: J. of Material Processing Technology, Vol. 183 (2007), p.425.
