Research on the Measurement Method of the Sub-Pixel Image Motion Based on Optical Correlator

Abstract:

To measure the sub-pixel image motion of the sequence images which are captured by the high-speed camera at the high frame rate with poor SNR, the joint transform correlator (JTC) is used. The relative image motion of the two adjacent images can be measured by inputting these images into the correlator. The principle of this method is described, and the effect of the defocussing of the CCD in the JTC on the accuracy is analyzed. To research the measurement performance of the JTC concretely, the experiment platform is set up. By using different images with different image motion, the results showed that, the JTC can measure the sub-pixel image motion entirely even for the images with SNR=1, and the measurement error submits to the normal distribution, which implies zero mean and the RMS is no more than 0.12 pixel under the conspicuous level is equal to 0.05.

• Periodical: Advanced Materials Research (Volumes 271-273)
• Pages: 7-12
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.271-273.7
• Online since: July 2011
• Authors: Chao Fan, Tie Jun Yang, Hong Liang Fu, Yi Tao Liang
• Keywords: Image Motion, Joint Transform Correlator, Measurement, Sub-Pixel

References

[1] Andrei Dragulinescu, D Cojoc. Optical correlators: systems and domains of applications. Proc. of SPIE, Vol. 5972(2005), p. 59721F-1~59721F-8.

[2] Thomas J Grycewicz, Brian E Evansa, Cheryl S Laua. Joint transform optical correlation applied to sub-pixel image Registration. Proc. of SPIE, Vol. 5908(2005), p. 59080Z-1~59080Z-9.

DOI: 10.1117/12.620809

[3] G. S. Pati, Kehar Singh. Experimental and simulation studies on the performance of binary and gray-valuedjoint transform correlators under poor illumination conditions and nonoverlapping background noise. Opt. Eng., Vol. 36(1997), p.1918– (1929).

DOI: 10.1117/1.601398

[4] G.S. Pati, K. Singh. Pattern Recognition Using Versatile Hybrid Joint-Transform Correlators: Some Techniques for Improving the Performance. Proc. of SPIE, Vol. 3729(1999), pp.66-80.

DOI: 10.1117/12.346763

[5] A. Alsamman, Spatially efficient pseudo-random phase encoded JTC for fast target recognition. Proc. of SPIE, Vol. 5816(2005), pp.252-257.

DOI: 10.1117/12.607974

[6] K. S. Bist, S. C. Jain. An efficient method of noise removal in Joint Transform Correlator. Proc. of SPIE, Vol. 4387(2001), pp.103-108.

[7] Chun-Te Li, Shizhuo Yin, Francis T. S. Yu. Nonzero-order joint transform correlator. Opt. Eng., Vol. 37(1998), p.58–65.

DOI: 10.1117/1.601856

[8] Hongxia Wang, Junfa He, Zhaoxuan Sheng. Optoelectronic hybrid joint transform correlator based on power spectrum subtracting and exponential filtering. Proc. of SPIE, Vol. 5642(2005), pp.445-450.

DOI: 10.1117/12.574410
