The Study of Welding Power-Arc System Stability Based on DFCD

Abstract:

Regarding welding power-arc system stability (WPSS) as the research object, the paper uses differential theory and considers the full load conditions from the external circuit on the course of dynamic welding, and some models about WPSS are found, they can obtain the analytic expression of system stability coefficient, and a qualitative analysis of WPSS' conditions is so born, on this basis, by the method of the relative conversion of current deviation, a dynamic factor of current deviation (DFCD) is obtained by analytical equation，then to quantify stability of the system by the way of decay time of deviation. Test's results, based on analysis of voltage and current waveforms, are the same to quantify the WPSS based on DFCD.

• Periodical: Advanced Materials Research (Volumes 284-286)
• Pages: 141-146
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.284-286.141
• Online since: July 2011
• Authors: Chun Tian Li, Chang Hua Du, Yi Luo, Hui Bin Xu
• Keywords: Decaying Time, DFCD, Stability, System’s Models

References

[1] Shisheng, Huang. The power for arc welding and digital control. [M]. Beijing: Mechanical Industry Press, 2007.35-36.

[2] Kang MJ, Rhee S. arc stability estimation and control for arc stabilization in short circuit transfer mode of C02 arc welding. Science and Technology of welding and Joining, 200l, 6 (2): 95-102.

DOI: 10.1179/136217101101538596

[3] Tusek, Janez, (Inst za varilstvo Ptujska). Influence of wire extension length on the welding process [J]. International Journal for the Joining of Materials, 1996, 8(3): 112-120.

[4] W.-P.Sung, K-S. Chen, M-H. Shih. Quantity analysis for welding performance in manufacturing processes [J]. Manuf Technol, 2004, 23:707-711.

[5] Lu shanping, FUJII HIDETOSHI, NOGI KIYOSHI.Effects of CO2 shielding gas additions and welding speed on GTA weld shape. [J] Journal of Materials Science 40 (2005) 2481–2485.

DOI: 10.1007/s10853-005-1979-7

[6] Shisheng, Huang. Arc Power [M]. Beijing: Mechanical Industry Press, 2004.4-30.

[7] Shuyan Yin. The Principles and Adjustment of the Welding Equipments for GMAW. [M]. Beijing: Mechanical Industry Press, 2000. 5-25, 35-44.

[8] L.T. Magazinnik, G.G. Magazinnik, A.G. Magazinnik.Power coefficient and power circuits of modern inverter-type welders.[J] Russian Electrical Engineering, Volume 08, Number6, 331-336.

DOI: 10.3103/s106837120906008x

[9] Yu. M. Mironov, Effect of the secondary current lead resistances on the properties of an arc steel-melting furnace as a receiver and transformer of electric power. [J]. 2009, No. 5, p.13–18

DOI: 10.1134/s0036029509080138

[10] Marco Ramírez, Gerardo Trapaga.Mathematical modeling of a direct current electric arc: Part I. Analysis of the characteristics of a direct current arc.[J] Metallurgical and Materials Transactions B, 2004, Volume 35, Number 2, Pages 363-372.

DOI: 10.1007/s11663-004-0036-2

[11] V A Lebedev, V S Romanyuk.Single-phase welding current power sources for mechanised carbon dioxide welding. [J] Welding International, 2004, Volume 18, Number 6, Pages 489-493.

DOI: 10.1533/wint.2004.3309

[12] G. P. Kornilov, A. A. Nikolaev, A. Yu. Kovalenko, E. A. Kuznetsov. Means and trends of reactive power management at large ironworks. [J]. Russian Electrical Engineering, 2008, Volume 79, Number 5, Pages 248-253.

DOI: 10.3103/s1068371208050052
