Finite Element Analysis and Optimization of Spreading System of Rapid Prototyping Machine for Ceramic Parts Based on ANSYS

Abstract:

3D modle of spreading platform of rapid prototyping machine for ceramic parts is established in PRO/E, and the modle is input to ANSYS, and the finite element analysis modle of the spreading platform is established by plane elemet; According to the structural strength of the experimental condition, considering the gravity of spreading platform to get the splatform’s stress annlysis and structure deformation in the different working conditions. And the dagenrous section is identitied to provide evidence for the further research, and aslo to provide a reference for other similar products.

• Periodical: Advanced Materials Research (Volumes 284-286)
• Pages: 1974-1980
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.284-286.1974
• Online since: July 2011
• Authors: Dong Qiang Gao, Fei Zhang, Zhi Gang Guo
• Keywords: Finite Element Analysis (FEA), Optimization, Spreading System of Rapid Prototyping Machine
