Design and Test of Silent Chain Including Silicon Fluorine Rubber Link Plate

Abstract:

In order to reduce the meshing noise of silent chain drive, a new concept of the chain (silent chain including silicon fluorine rubber link plate) was proposed. It could change the meshing contact state by changing the shape of traditional steel chain plate and arranging the silicon fluorine rubber link plate reasonably, which reduced meshing impact, so the meshing noise was reduced. Through the platform contrast test, a noise test was made with different types of silent chain at the same speed, and the results shown that the silent chain including silicon fluorine rubber plate drove more smoothly than other silent chains, the level of noise was reduced 2dB～3dB, which verified the fact that the silent chain including silicon fluorine rubber link plate could reduce noise.

• Periodical: Advanced Materials Research (Volumes 291-294)
• Pages: 2002-2005
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.291-294.2002
• Online since: July 2011
• Authors: Xiao Lun Liu, Song Ding, Wei Sun, Wen Cheng Wang, Jia Jun Liu, Bin Jiang
• Keywords: Chain Drive, Noise Reduction, Silent Chain, Silicon Fluorine Rubber

References

[1] I. Troedsson, L. Vedmar. Journal of Mechanical Design. Vol. 121(1999), p.402

[2] H. ZHENG, Y. Y.WANG, G. R. LIU, K. Journal of Sound and Vibration. Vol. 245(1999), p.133

[3] I. Troedsson, L. Vedmar. Journal of Mechanical Design. Vol. 123(2001), p.395

[4] Zhaowen LI. Second International Conference on Computer Modeling and Simulation.(2010).

[5] Min FAN, Zhenhua MA, Yue CHEN. Journal of Materials Review Online. Vol. 5(2008), p.16
