Study on Fengdu Second Yangtze River Bridge the Cable Anchorage Structure in a Girder Transfer Mechanism

Abstract:

The cable anchorage region in a girder is the key part of cable stayed bridge， in which stress distribution is rather complicated. A general plane analysis method is hard to reflect actual stress status. According to the design of Fengdu Second Yangtze River Bridge In this paper, the analysis of the spatial stress distribution of the cable anchorage structure in a girder is carried out in design load by making use of the common analysis software-Midas FEA and spatial finite element method, the verification and assessment of Fengdu Second Yangtze River Bridge Anchor Plate rational structural design is conducted, in order to put forward optimize the design suggestions, to ensure that such structures the realization of economy and reliability.

• Periodical: Advanced Materials Research (Volumes 291-294)
• Pages: 2320-2323
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.291-294.2320
• Online since: July 2011
• Authors: Xie Dong Zhang, Jin Zhi Wang, Xiao Dong Wang
• Keywords: Cable Anchorage Structure in a Girder, Spatial Finite Element, Tensile Anchor Plate

References

[1] WU Xiushui & Xin Kegui.:Lateral Bucking Analysis of Thin-Walled Members by Finite Member Element Method. Engineering Mechanics. Vol. 18(2001),pp.47-55.

[2] He Shuanhai: Bridge structure theory and computational method (People's Traffic Press, Beijing 2003). In Chinese.

[3] Wang Xu Cheng & Shao Min: The basic principles of finite element method and numerical methods(Tsinghua University Press, Beijing 1996). In Chinese.
