Research on Calculation and Smoothing of Grinding Wheel Profile for Machining Screw Rotor

Abstract:

Upon studying the form grinding principle of helical groove and the conjugate movement between the grinding wheel and screw rotor, the equation of their contact line is firstly derived. The problem of smoothing the profile of grinding wheel is then solved by using the point selection smoothing method which is concludes from the theory of complex curves and numerical analysis. Finally, with the help of computer, the simulation processing is done with the final result shows that this design method is reliable. It can not only reduce the time for design and the number of trial samples but also provides a 3D model which can be used in virtual test of screw rotor.

• Periodical: Advanced Materials Research (Volumes 291-294)
• Pages: 2383-2387
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.291-294.2383
• Online since: July 2011
• Authors: Zhi Huang Shen, Ru Sheng Lu, Zhe Shan Zhang, Bin Yao
• Keywords: Forming Grinding Wheel, Helical Groove, Screw Rotor, Smoothing Method

References

[1] Ziwen Xing. Screw Compressor-Theory, Design and Application[M]. China Machine Press: BeiJing, Aug. 2008. (In Chinese)

[2] Liming Chen. Tool Engineering. Vol. 39 (2005), pp.72-74. (In Chinese)

[3] Jing Wei, Guanghui Zhang. International Journal of Advanced Manufacturing Technology. Vol. 84 (2010), pp.495-503. (In Chinese)

[4] Xutang Wu. Principle of Gear Engagement [M]. Xi'an Jiaotong University Press.2009.3.

[5] Rusheng Lu, Bin Yao. Advanced Materials Research. Vol. 139 (2010), pp.1264-1267.

[6] Rusheng Lu, Bin Yao, Fei Li. International Conference on Manufacturing Science and Technology (2010.11), p.236－239.

[7] Rong Mo, Ying Wu, Zhiyong Chang. Computer Aided Geometry Modeling [M].Science Press. 2004.2. (In Chinese)

[8] C.M. Zhang, P.F. Zhang, F.H. Cheng. Computer-Aided Design. Vol. 33 (2001) , pp.913-923.

[9] Wei Xiong, Quanke Feng. Fluid Machinery. Vol. 133 (2005), pp.30-33. (In Chinese)
