Modeling Variation Propagation Based on State Space and its Application to Dimensional Variation Prediction in Shipbuilding

Abstract:

Dimensional control is one of the most important challenges in shipbuilding industry. In order to predict assembly dimensional variation in block construction of shipbuilding, a variation stream model based on state space is presented in this paper, which can be further applied to accuracy control. Both locating error and welding deformation are taken into consideration in this model, and variation propagation mechanisms and accumulative rule in the assembly process are analyzed, then, a model is developed to describe the variation propagation throughout the assembly process, finally, an example of flat block construction is given to provide this method is effective and useful.

• Periodical: Advanced Materials Research (Volumes 291-294)
• Pages: 2889-2892
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.291-294.2889
• Online since: July 2011
• Authors: Xiang Rui Liu, Zhi Ying Zhang
• Keywords: Multi-Station Assembly, Shipbuilding, State Space, Variation Propagation

References

[1] Liu S.,Hu S.J.: Internal Journal of Machine Tools and Manufacturing Vol. 35 (1995), p.1545

[2] Hu S.J.: Annals of the CRIP, Vol. 46 (1997), p.1

[3] Jin J.,Shi J.: ASME Journal of Manufacturing Science and Engineering Vol. 121 (1999), p.756

[4] Shiu B.,Ceglarek,D.,Shi J.: NAMR/SME Transactions Vol. 23 (1996), p.199

[5] Zhaoqing Tian: Chinese Journal of Mechanical Engineering Vol. 43 (2007), p.202

[6] Bochuan Chen: "Welding engineering analysis and countermeasure" (In Chinese), CM Press, (2006)

[7] Zhibin Zeng, Zhiqiang Shi, Yongji Shi: China Railway Science Vol. 30 (2009), p.33
