Gas Bubble Behavior Model in Adhesive Bonding Using Thermosetting Polymer

Abstract:

Gas bubbles entrapped in polymer intermediate layer often lead to voids which are severe defects of adhesive bonding qualities. Although the empirical method had been used for a long time to eliminate the bubbles, theoretic analysis considering the bubble behavior during bonding process is more preferable because of the better universality. The interrelationships between processing parameters and bubble deformation were investigated. A theoretic model describing those interrelationships was developed reasonably using gas diffusion theory to predict the bubble behavior. The mathematic equations of this model were deduced and the solution was obtained with some proper simplifications. Experiments under different conditions were carried out and the experimental results were contrasted with the theoretical predictions. It was obvious that when choosing temperatures and pressures carefully, the model could predict the bubble behavior accurately.

• Periodical: Advanced Materials Research (Volumes 291-294)
• Pages: 527-531
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.291-294.527
• Online since: July 2011
• Authors: Lei Nie, Yu Ning Zhong, Ye Peng Zhang
• Keywords: Adhesive Bonding, Bubble Free, Gas Bubble, Gas Diffusion

References

[1] J. Oberhammer, F. Niklaus, G. Stemme, Selective wafer-level adhesive bonding with benzocyclobutene for fabrication of cavities, Sensor. Actuat. A-Phys. 105 (2003) 297-304.

DOI: 10.1016/s0924-4247(03)00202-4

[2] J. Oberhammer, G. Stemme, BCB contact printing for patterned adhesive full-wafer bonded 0-level packages, J. Microelectromech. S. 14 (2005) 419-425.

DOI: 10.1109/jmems.2004.839030

[3] F. Niklaus, G. Stemme, J.Q. Lu, R.J. Gutmann, Adhesive wafer bonding, J. Appl. Phys. 99 (2006) 031101-031128.

DOI: 10.1063/1.2168512

[4] T. Nonaka, K. Fujimsru, N. Asahi, K.i. Kasumi, Y. Matsumoto, Development of wafer level NCF (non conductive film), in: Electronic Components and Technology Conference, 2008. ECTC 2008. 58th, 2008, pp.1550-1555.

DOI: 10.1109/ectc.2008.4550182

[5] S. Abdullah, S. Mohd Yusof, I. Ahmad, A. Jalar, R. Daud, Dicing Die Attach Film for 3D Stacked Die QFN Packages, in: Electronic Manufacturing Technology Symposium, 2007. IEMT '07. 32nd IEEE/CPMT International, 2007, pp.73-75.

DOI: 10.1109/iemt.2007.4417054

[6] P. Jongwoo, J. Taweeplengsangsuke, C. Theis, J. Osenbach, Epoxy adhesive used in optical fiber/passive component: kinetics, voids and reliability, in: Electronic Components and Technology Conference, 2001. Proceedings., 51st, 2001, pp.637-644.

DOI: 10.1109/ectc.2001.927796

[7] F. Niklaus, P. Enoksson, E. Kalvesten, G. Stemme, Void-free pull wafer adhesive bonding, in: Micro Electro Mechanical Systems, 2000. MEMS 2000. The Thirteenth Annual International Conference on, 2000, pp.247-252.

DOI: 10.1109/memsys.2000.838524

[8] J.R. Wood, M.G. Bader, Void control for polymer-matrix composites (1): Theoretical and experimental methods for determining the growth and collapse of gas bubbles, Composites Manufacturing, 5 (1994) 139-147.

DOI: 10.1016/0956-7143(94)90023-x

[9] J.R. Wood, M.G. Bader, Void control for polymer-matrix composites (2): Experimental evaluation of a diffusion model for the growth and collapse of gas bubbles, Composites Manufacturing, 5 (1994) 149-158.

DOI: 10.1016/0956-7143(94)90024-8

[10] H. S. Carslaw and J. C. Jaeger, Conduction of Heat in Solids, Second ed., Oxford, (1959)
