Study of the Structural Characteristics of Mold for Precise Injection Molding

Abstract:

With the improvement of accuracy requirements for industrial products, the precise injection molding is replacing the traditional injection molding quickly and widely. Many factors influence the quality of injection-molded parts greatly, such as the property of the plastics, mold structure and the manufacturing accuracy, injecting machine and the injecting process parameters. In this paper, the work is emphasized for the influence of mold structure on the quality of injection-molded parts. Eight portions of injection mold are analyzed, including the cavities and cores, the guide components, the runner system, the ejection system, the side-core pulling mechanism, the temperature balance system, the venting system and the supporting parts. The structural characteristics of the above eight portions are presented.

• Periodical: Advanced Materials Research (Volumes 291-294)
• Pages: 610-613
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.291-294.610
• Online since: July 2011
• Authors: Hong Lin Li, Zhi Xin Jia
• Keywords: Injection Molding, Plastic Part, Precise Injection Mold

References

[1] Z.G. Chen. Injection Mold Design ( China Machine Press, China 2003). (in Chinese)

[2] Ashis Gopal Banerjee, Satyandra K. Gupta: Computer-Aided Design, Vol.39 (2007), p.882–897.

[3] C.G. Li, C.L. Li: Computer-Aided Design, Vol.40 (2008), p.334–349.

[4] H.L. Li, Z.G. Li: Die & Mould Industry, Vol. 30 (2004) No.6, pp.29-31. (in Chinese)
