Numerical Simulation and Experimental Study on Warm Forging Process of Half Axle Bevel Gear

Abstract:

According to the shape character of half axle bevel gear forging a process based on closed-die forging scheme was proposed. Based on a series of simulation the influence of initial forging temperature on forming force, the influence of web thickness and web position on stress, damage factor and forming force were analyzed. According to numerical analysis the web dimensions and forging temperature which ensure a minimum stress, a minimum damage factor and a proper forming load were achieved. The forming result was simulated and evaluated, and the forming load was controlled under 760ton. At last the research project got good test verifying.

• Periodical: Advanced Materials Research (Volumes 291-294)
• Pages: 774-777
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.291-294.774
• Online since: July 2011
• Authors: Ying Tong
• Keywords: Crankshaft, Heat Conduction, Volume Forming, Wear

References

[1] Chen X.W., DongWon J.. Gear hot forging process robust design based on finite element method [J]. Journal of Mechanical Science and Technology, 2008, 22(9): 1772-1778.

DOI: 10.1007/s12206-008-0515-5

[2] A.R.O. Abdel-Rahman, T.A. Dean. The quality of hot forged spur gear forms. Part I: Mechanical and metallurgical properties [J]. International Journal of Machine Tool Design and Research, 1981, 21(2): 109-127.

DOI: 10.1016/0020-7357(81)90003-2

[3] Juan Liu, Zhenshan Cui. Hot forging process design and parameters determination of magnesium alloy AZ31B spur bevel gear [J]. Journal of Materials Processing Technology, 2009, 209(18-19): 5871-5880.

DOI: 10.1016/j.jmatprotec.2009.06.015

[4] Xuewen Chen, Dongwon Jung, Aixue Sun. Hot forging process design optimization based on approximate model and FEM simulation [J]. Materials Science Forum, 2008, 575-578: 334-339.

DOI: 10.4028/www.scientific.net/msf.575-578.334
