Effect of Floating Die on Tooth Filling of Spur Gear Forging

Abstract:

According to the analysis of friction distribution on radial direction in the precision forging spur gear, the reason that the tooth corner was difficult to fill is revealed. Changing the motion mode of the floating die will change the friction condition between billet and floating die, as well as the filling situation of tooth corner. Finally, the scheme was further validated by DEFORM-3D, and the results show that the validity of floating die to tooth corner filling.

• Periodical: Advanced Materials Research (Volumes 295-297)
• Pages: 1631-1634
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.295-297.1631
• Online since: July 2011
• Authors: Cheng Yang, Sheng Dun Zhao
• Keywords: Floating Die, Precision Forging, Spur Gear

References

[1] Kyoichi OHGA, Kazuyoshi KONDO. Bulletin of JSME, 1982, 25(209):1828-1835.

[2] Kyoichi OHGA, Kazuyoshi KONDO. Bulletin of JSME, 1982, 25(209):1836-1842.

[3] Kyoichi OHGA, Kazuyoshi KONDO. Bulletin of JSME, 1982, 25(209):1843-1850.

[4] Kyoichi OHGA, Kazuyoshi KONDO. Bulletin of JSME, 1983, 26(218):1434-1441.

[5] Kyoichi OHGA, Kazuyoshi KONDO. Bulletin of JSME, 1985, 28(244):2451-2459.

[6] C.Tuncer, T.A. Dean.International Journal of Machine Tools and Manufacture, 1987, 27(1):65-76.

[7] C.Tuncer, T.A. Dean. Journal of Mechanical Working Technology, 1988,2988(16):39-50.

[8] J. Cai, T.A. Dean, Z.M. Hu. Journal of Materials Processing Technology,150(2004):48-55.

[9] Zhipin Lin, Zeqiu Tao, Xianfeng Tan. Forging & Stamping technology,1999,2:9-12. In Chinese

[10] Fuxiang Tian. Forging & Stamping technology,1998,2:57-59.In Chinese

[11] Shuqing Kou, Peifu Fu. Journal of Harbin Institute of Technology,2000,32(4)68-71.In Chinese

[12] Rongfang Qian. Forging & Stamping technology,2002,1:1-3.In Chinese

[13] E. Doege, R. Bohnsack. Journal of Materials Processing Technology, 98(2000):165-170.
