Self-Assembly Proton Exchange Membranes for Direct Methanol Fuel Cell with Size-Controlled Au Nanoparticles

Abstract:

Charged Au nanoparticles with various diameters, from 2.7 nm to 10.3 nm, were synthesized by using various reducing agents. Then charged Au nanoparticles were self-assembled onto the NafionTM membrane surface as methanol barriers. It was found that the proton exchange membrane self-assembled with 3.9 nm Au particles had the lowest methanol crossover. The proton conductivity decreased with the increase of the particles size until the particles size was more than 6.2 nm and they had little influence on the membrane conductivity. All the self-assembled membranes have higher open circuit voltage (OCV) and performance than original Nafion212TM membrane. And the membranes self-assembled with 3.9 nm poly (diallymethylammonium chloride) (PDDA) modified Au (PDDA-Au) particles had the highest performance due to the reciprocal of the methanol permeation current density and membrane area resistance.

• Periodical: Advanced Materials Research (Volumes 306-307)
• Pages: 108-111
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.306-307.108
• Online since: August 2011
• Authors: Ai Ping Jin, Zhao Hui Wan, Kai Chen Lei
• Keywords: Methanol-Blocking Proton Exchange Membrane, Nanoparticle, Self-Assembly

References

[1] J. Divisek and M. Eikerling, Study of capillary porous structure and sorption properties of Nafion proton-exchange membranes swollen in water, J. Electrochem. Soc. 145 (1998) 2677-2683.

DOI: 10.1149/1.1838699

[2] M.W. Verbrugge, Methanol diffusion in perfluorinated ion-exchange membranes, J. Electrochem. Soc. 136 (1989) 417-423.

DOI: 10.1149/1.2096646

[3] H. Tang, M. Pan, S. Jiang, Z. Wan and R. Yuan, Self-assembling multi-layer Pd nanoparticles onto Nafion™{TTP}8482 membrane to reduce methanol crossover, Colloids Surf., A Vol. 262 (2005) 65-70.

DOI: 10.1016/j.colsurfa.2005.04.011

[4] S. Mu, H. Tang, Z. Wan, M. Pan, R. Yuan, Au nanoparticles self-assembled onto Nafion membranes for use as methanol-blocking barriers, Electrochem. Commun. 7 (2005) 1143-1147.

DOI: 10.1016/j.elecom.2005.08.019

[5] F.P. Orfino, S. Holdcroft, The morphology of Nafion: are ion cluster bridged by channels or single ionic sites, J. New Mat. Electr. Sys. 3 (2000) 285-290.

[6] B. Libby, W.H. Smyrl, E. L. Cussler, Composite membranes for direct methanol fuel cells, Electrochem. Solid-State Lett. 4 (2001) A197-A199.

DOI: 10.1149/1.1413183

[7] Z. Qi, A. Kaufman, Open circuit voltage and methanol crossover in DMFCs, J. Power Sources 110 (2002) 177-185.

DOI: 10.1016/s0378-7753(02)00268-9

[8] J. Larminie, A. Dicks, Fuel Cell System Explained, Second ed., John Wiley, Chichester, England (2003).
