Effect of Anisotropic Membrane Surface Modification of Nafion Based Ionic Polymer-Metal Composites

Abstract:

In order to enhance the electromechanical characteristics of IPMCs actuators under low voltage, a set of anisotropic membrane surface modification techniques, including roughness along, roughness across and roughness across both directions, is proposed in this paper. Three groups of IPMCs samples based on corresponding roughness direction have been prepared to validate the these surface modification. Experiments have been made to measure the electromechanical characteristics of the samples. The results show that the IPMCs actuator with micro-grooves being across the length of the IPMCs actuator could improve the IPMCs’ tip blocking force and deflection, and it exhibits blocking forces by 10% larger than the conventional IPMCs while its displacement is approximately 8% larger. We can conclude that an appropriate anisotropic surface modification could be an effective method to create a preferred bending force and to enhance the bending margin of IPMCs actuators.

• Periodical: Advanced Materials Research (Volumes 311-313)
• Pages: 2000-2004
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.311-313.2000
• Online since: August 2011
• Authors: Hong Lin He, Jun Ping Wang
• Keywords: Anisotropic Surface Modification, Blocking Force, Deflection, Electroless Plating (EP), IPMCS

References

[1] Kwang J Kim and Mohsen Shahinpoor: Ionic polymer–metal composites: Ⅱ. Manufacturing techniques. Smart Material and structures. Vol.12 (2003), p.65~79

DOI: 10.1088/0964-1726/12/1/308

[2] Mohsen Shahinpoor and Kwang J Kim: Ionic polymer–metal composites: Ⅲ.Modeling and simulation as biomimetic sensor, actuators, transducers, and artificial muscles. Smart Material and structures. Vol.13 (2004), p.1362~1388

DOI: 10.1088/0964-1726/13/6/009

[3] Ning Jin and Bangfen Wang: Effect of surface roughening on the manufacture and performance of IPMC in Chinese. Journal of Functional Materials. Vol.11 (2008), p.1933~(1936)

[4] Boyko L. Stoimenov, Jonathan M: Rossiter: Anisotropic surface roughness enhances bending response of ionic polymer-metal composite (IPMC) artificial muscles. Smart Materials IV. Vol.12 (2006), p.121~130

DOI: 10.1117/12.695665

[5] N Bhat1, W-J Kim1: Precision force and position control of an ionic polymer metal composite. Professional Engineering Publishing. Vol.4 (2004), p.421~432

[6] Sia Nemat-Nasser, Shahram Zamani: Experimental Study of Nafion- based and Flemion-based Ionic Polymermetal Composites (IPMCs) with Ethylene Glycol as Solvent. Smart Structures and Materials: Electroactive Polymer Actuators and Devices (EAPAD).Vol.3 (2003), p.233~244

DOI: 10.1117/12.488551

[7] Xiangqiang Tan, Yingchun zhong: Characteristics and Application of artificial muscles in Chinese. High Technology Letters. Vol.1 (2002), p.50~52

[8] Soon-Gie Lee, Hoon-Cheol Park: Performance Improvement of IPMC (Ionic Polymer Metal Composites) for a Flapping Actuator. International Journal of Control, Automation, and Systems. Vol.4 (2006), p.748~755

[9] Dibakar B，James N: Estimation of Bending Resistance of Ionic Polymer Metal Composite (IPMC) Actuator Following Variable Parameters Pseudo- rigid Body Model. Materials Letters, Vol.63(2009), p.745~747

DOI: 10.1016/j.matlet.2008.12.048
