Bond Interface Evaluation by Ultrasonic Testing and SEM for Radial Friction Welding Joints of Copper and Steel

Abstract:

The bonds of T2 copper/50steel were studied by inertial radial friction welding techniques at different conditions. Ultrasonic C-scan testing was employed to evaluate the bonding situation. In order to verify the reliability of ultrasonic C-scan testing results, the optical microscope, SEM and shear test were used to analyse the microstructure and mechanical properties. It was found that ultrasonic C-scan testing was useful to evaluate the inertial radial friction welding joint situations by analyzing the ratio of good bonded area in the bond area of ultrasonic C-scan images. And the correctness of ultrasonic C-scan testing was testified by microstructure examination. Furthermore, it was concluded that enough metalline plastic deformation occurred, oxide film of joint was destroyed and constituent elements were mutually diffused sufficiently, when two stage pressure was employed and friction pressure 78 MPa, friction speed 3200r/min were used.

• Periodical: Advanced Materials Research (Volumes 328-330)
• Pages: 1457-1461
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.328-330.1457
• Online since: September 2011
• Authors: Wei Wu, Ling Yun Zhu, Guang Feng Wu
• Keywords: Copper Alloy, Radial Friction Welding, SEM, Steel, Ultrasonic Testing (UT)

References

[1] Hiizu Och and Gosaku Kawai: Proceedings of the Eighteenth International Offshore and Polar Engineering Conference (Vancouver , BC, Canada , July 6-11, 2008), p.272.

[2] Mümin Ş AHİN: International Scientific Conferenc (Gabrovo, November19 – 20, 2010) , p.19.

[3] WeiWu, DongLinPeng and XiaolingXu: Study on Radial Friction Welding of Copper-alloy with Steel[J]. Ordnance Mater ial Scienceand Eng ineering , Vol. 29 (2006) No. 5, p.55 (In Chinese).

[4] WeiWu, DongLinPeng and XiaolingXu: Ultrasonic Immersion C-scan System and its Application in Detecting the Thin Copper-Steel Radial Friction Welding Joint[J]. Automation & Instrumentation, Vol. 5 ( 2006)No. 5, p . 40( In Chinese).

[5] WeiWu: Ultrasonic Testing method Study on Friction Welding Joints with Dissimilar Materials(Master's. D. , ChongQing University, China 2006), p.28(In Chinese).

[6] Ultrasonic Testing ASNT: Nondestructive Testing Handbook (China Machine PRESS, China, 2000), p.187(In Chinese).

[7] Hamed ABDEL-ALEEM: Quarterly Journal of the Japan Welding Society( Japan, 2005), Vol. 23, No. 2, p.194.

[8] H. Ochi: Proceedings of the Eleventh International Offshore and Polar Engineering Conference. (Stavanger , Norway, June 17-22, 2001), p.256.
