An Anti-Sway Controller’s Design of the Overhead Crane

Abstract:

This paper detailedly illustrates how to design an anti-sway controller of overhead crane for eliminating pendulum of hook-headed. First of all the paper uses Lagrange Equation in analytical mechanics to obtain a mathematical model of crane motion system in three dimensional space. Then the paper advances a new control method and designs an anti-disturbance tracking controller based on servo-compensator and stabilization compensator for eliminating pendulum of hook-headed and accurately fixing position. In general, it is difficult to design an appropriate control law because of the crane motion system’s nonlinearity and strong coupling. However, the control method the paper put forward is simple and effective, and ensures the transient state performance of closed-loop system preferable and stable. The paper will introduce the design steps of anti-sway controller of overhead crane and give a satisfying simulation result, which are new and original in this paper.

• Periodical: Advanced Materials Research (Volumes 328-330)
• Pages: 1868-1871
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.328-330.1868
• Online since: September 2011
• Authors: Bin Yang, Lin Ma
• Keywords: Anti-Sway Controller, Lagrange Equation, Servo-Compensator, Stabilization Compensator

References

[1] M.Q. Li: Frontiers of Electrical and Electronic Engineering in China, Vol. 4(2009) No. 4, p.417.

[2] Nenad Muskinja, Boris Tovornik: IEEE Trans on Industrial Electronics, Vol. 53(2006) No. 2, p.631.

[3] B. Han, X.G. Lin: IEEE Signal Processing Letters, Vol. 12(2005) No. 11, p.780.

[4] M. Hou: IEEE Trans on Automatic Control, Vol. 49(2004) No. 10, p.1723.

[5] Z.N. Masoud, A.H. Nayfeh: Journal of Vibration and Control, Vol. 9(2003) No. 1, p.257.
