Design and Application of Network Borehole-Ground Electrical Measurement System

Abstract:

Borehole-ground Electrical measurement is an important geophysical exploration method to determine the underground distribution of remaining oil. The author designs a set of network measurement system, where the intelligent electrodes were arrayed. Potentials are measured continuously to realize the dynamic monitoring. We adopt multi-channel simultaneous sampling and linear accumulated digital averaging to suppress electromagnetic noise. Feedback compensative method is used to exclude the influence of SP (spontaneous potential) and covers a wide dynamic measurable scope. In order to make all measurements validity, all electrodes earthing situation are collected. We present the oilfield survey data measured by this self-developed instrument. Practical application shows that the system is characterized with high efficiency, portable and strong anti-jamming capability.

• Periodical: Advanced Materials Research (Volumes 328-330)
• Pages: 1926-1929
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.328-330.1926
• Online since: September 2011
• Authors: Lei Shao, Jun Lin
• Keywords: Borehole-Ground Potential, Intelligent Electrode, Network, Remaining Oil

References

[1] Q. Zhou, A. Becke and H.F. Morrison: Geophysics, Vol. 58 (1993) No. 4, p.482.

[2] G.M. Hoversten, G.A. Newman and H.F. Morisson: Geophysics, Vol. 66 (2001) No. 4, p.1177.

[3] J.Z. Gao: Detection of Weak Signal (Tsinghua University Press, China 2004) (In Chinese).

[4] Z.W. Li, Y.Y. Zhou and R. Feng: Progress in Geophysics, Vol. 19 (2004) No. 4, p.812.
