Investigation on Influence of Launch Depth to the Hydrodynamic Characteristics of the Cylinder out of the Tube

Abstract:

The influence of different the depth to the hydrodynamic characteristics of the underwater cylinder vertical launch out of the tube was researched with numerical simulation. The finite volume method based on the multiphase model, continuity equation, transport equations of liquid mass fraction,a dynamic mesh technique and a standard tow-turbulence model are adopted to solve RANS equation in conjunction. The fluid-solid coupling problem of both movement boundary of the cylinder and multiphase flow field was solved by using numerical method. Under the influence of the gravity, the flow field affected the hydrodynamic characteristics of the cylinder was derived with the numerical simulation. Simulation results show that different launch depths affect on the trajectory of underwater cylinder and hydrodynamic. The fluctuation reasons of different pressure drag coefficient, viscous drag resistance coefficient and toll resistance coefficient were derived by analyzing simulation results.

• Periodical: Advanced Materials Research (Volumes 328-330)
• Pages: 2261-2264
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.328-330.2261
• Online since: September 2011
• Authors: Hai Jun Liu, Xing Zhi Peng, Cong Wang, Ben Li Wang
• Keywords: Hydrodynamic Characteristics, Multiphase Flow, Partial Cavitation, Underwater Cylinder, Vertical Launch

References

[1] Yan kai, Wang bao-shou. Some of research progress of water-exit cavity[c]. Proceedings of the 21st National Conference on Hydrodynamics and 8th National Congress on Hydrodynamics and the Cross-Strait Conference on Ship and Ocean Engineering Hydrodynamics. 2008. 9-17.

[2] Huang shou-kang. Fluid dynamic·Trajectory·Environment. Bei jing. 1991, Aerospace press.

[3] Jon J. Yagla, Launch dynamics Environment of a Water Piercing Missile Launcher . Conference. 2007, San Diego.

[4] Weiland, Pavlos, Jon J. Yagla. Concept analysis and laboratory observations on a water piercing missile launcher[J]. Ocean Engineering. 2007. 3(9): 959-965.

DOI: 10.1016/j.oceaneng.2010.03.009

[5] Liu yun-qiao, Lu chuan-jing, Li jie, et al. An investigation of ventilated cavitating flow in vertical launching of a missile[J]. Journal of hydrodynamics. 2007, A, 22(5): 549-554.

[6] Zhang hong-jun, Lu hong-zhi , Pei yin. Numerical investigation to vertical launching of submarine launching missile[J]. Chinese journal of hydrodynamics. 2010, 25(3): 405-415.

[7] Rouse H, McNown JS. Cavitation and pressure distribution, head forms at zero angle of yaw. Studies in Engineering, State University of Iowa, 1948, Bulletin, 32.

DOI: 10.17077/006207
