Design and Application of Forced Heat Dispersing Device of Superdeep Drilling Rig in High Temperature

Abstract:

The system about the eddy current brake in drilling rig is very important and friable component. The temperature will arise with the winch lift the heave object and break, which will affect the winch. The conventional drilling rigs are cooled by air blast or water circulation, which always can’t content the request of drilling rig winch brake system. For this situation, I am to design and manufacture the forced heat-dispersing unit for ZJ70/4500DZ drilling rig winch. This device unified the formerly forced-air cooling and water cooling characteristic, and what’s more, it consists of air cooler, water tank, water pump valves, manifold and instruments. It has lots of advantages, for example: structure compact, easy installation and maintenance and so on. The article in the bases of analyses the ZJ70 drilling rig winch system characteristic and the theory of the formerly heat-dispersing, to introduced the approach of design and composition design…

• Periodical: Advanced Materials Research (Volume 339)
• Pages: 561-565
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.339.561
• Online since: September 2011
• Authors: Ze Fu Bao, Hai Feng Dai, Peng Zang, Jiang Ping Wang
• Keywords: Eddy Current Brake, Forced Heat Dispersing Device, Higher Temperature, Superdeep Drilling Rig

References

[1] Yiwei ma. The design and application of air cooler[M] . harbin: harbin industial university press, (1988)

[2] Songhan wang, xuzhi zhang, haohan yu, etc. Petroleum chemical engineering design manual the third unit chemical unit process[M]. Beijing : chemical industry press, 2001.

[3] Yuping cao, xiangan, yan, etc. Hydraulic drive and control[M]. The second edition. Tianjin; tianjin university press, 2003.
