An Optimal Construction of a Hydropower Arch Gate

Abstract:

A new design scheme of an emersed hydropower arch gate is presented based on topology optimization method. Three main components of the gate, i.e., two arms, a water-retaining face plate and its supporting frame, are considered in the present design method. Both of the layouts of the arms and the supporting frame are obtained by using topology optimization method instead of traditional experiments. In design process, firstly, the location, topology and shape of the arms of gate are obtained. Secondly, the layout of ribs in the support frame is found. Finally, the integrated structure is formed by using the components obtained above and the new gate satisfies such constraints as strength, stiffness and stability. The new gate is about 30% lighter than the one obtained by using traditional method, which means much material is saved and the new gate can be easier for operating.

• Periodical: Advanced Materials Research (Volume 346)
• Pages: 109-115
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.346.109
• Online since: September 2011
• Authors: Kun Cai, Chao Zhang
• Keywords: Arch Gate, Hydraulic Structure, Hyperworks, Topology Optimization

References

[1] The Ministry of Water Resources of the People's Republic of China, Hydraulic and hydroelectric engineering specification for design of steel gate, Power Industry Press, Beijing, 1995. (in Chinese).

[2] J. J. Lian and H. K. Li, Optimization design for the main frame of radial gate using SQP arithmetic, Water Resources and Hydropower Engineering, 2004, Vol. 35, No. 9, pp.63-66. (in Chinese).

[3] Y. Q. Cai, etc., Integrated optimization of structural design of radial gate, Engineering Journal of Wuhan University, 2005, Vol. 38, No. 6, pp.20-23. (in Chinese).

[4] B. Peng, Study of a new optimization theory based on GA and its application in arch gate optimization, " Master, s thesis, Wuhan University, Wuhan, 2006. (in Chinese).

[5] M. P. Bendsoe and N. Kikuchi. Generating optimal topologies in structural design using a homogenization method, Computer Methods in Applied Mechanics and Engineering, 1988, Vol. 71, No. l, pp.197-224.

DOI: 10.1016/0045-7825(88)90086-2

[6] M. P. Bendsoe and O. Sigmund, Topology optimization: theory, methods and applications, Springer, (2003).

[7] http: /www. altair. com/Default. aspx.

[8] J. Z. Zhu, etc., Application of topology optimization to optimized layout of large-scale radial steel gate, Yellow River, 2007, Vol. 29, No. 6, pp.63-64. (in Chinese).
