Loading Analysis of Edge Members in SPSW with Opening

Abstract:

Taking a group of SPSW with openings with or without edge members as example, this paper states the importance of edge members in view of initial stiffness, ultimate bearing capacity and ductility. First, FEM analysis is carried out to study the reasonable stiffness-range and it is found out when the inertia moments ratio varies from 6 to 8, edge members not only provide adequate anchorage, but also resist loads directly with main frame. Then, an unified calculation model called USMO is proposed, whose key point is to add inversed compression bars with stiffness to tension zone to simulate the increase of ultimate bearing capacity, leaving shearing part same to USM.

• Periodical: Advanced Materials Research (Volumes 368-373)
• Pages: 1384-1387
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.368-373.1384
• Online since: October 2011
• Authors: Tao Lan, Ji Ping Hao, Hai Jun Xu
• Keywords: Edge Member, SPSW with Opening, Stiffness-Range, Ultimate Bearing Capacity and Ductility, USMO Model

References

[1] Tao Lan, Study on the Construction Design Theory and Methods of Steel Plate Shear Wall with Openings. The degree of Doctor, Xi'an: Xi'an University of Architecture & Technology, 2011, In Chinese

[2] ANSI-AISC-341-05, Seismic Provisions For Structural Steel Buildings. Chicago, (2005)
