The Elastic Analysis of Finite Element to the Shell of Blast Furnace under Thermal - Structural Coupling

Abstract:

Stress distribution of blast furnace shell is important to the security of structural system. According to real loads of blast furnace and temperature loads, this paper carries on the analysis of elastic finite element to a blast furnaces utilizing the software ANSYS. The result shows that most areas of the blast furnace are in elastic state, and only a few around holes are in plasticity state as the result of stress concentration; temperature loads have great influence over the structure stress and displacement. We obtain the stress distribution of blast furnace that is useful in the design of subsequent blast furnace.

• Periodical: Advanced Materials Research (Volumes 368-373)
• Pages: 1495-1499
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.368-373.1495
• Online since: October 2011
• Authors: Shan Hua Xu, Xin Long Yang, Jian Li, Bin Shi, Bin Qiu
• Keywords: Blast Furnace Shell, Finite Element Analysis (FEA), Thermal-Structural Coupling

References

[1] Dejin Jiang, On the structural design of blast furnace on, industrial building, 2003.6.

[2] Fuke Zhang etc, A large blast furnace shell steel structure integral elastic finite element analysis, industrial building, 2009 supplement.

[3] Zhijun Wang, Xi Chen etc, Steel new No.1 blast furnace shell elastic plastic finite element analysis, Industrial Construction, 2003,33(10).

[4] Kailin Zhang etc, Thermal structural coupling of blast furnace shell of static strength and fatigue strength analysis, Journal of Chongqing University, 2008.6.
