The Optimization Calculation Method Study on Longitudinal Lattice Girder of the Spray Anchor Bracing System

Abstract:

As the structure component of the spray anchor bracing system, at present the structure calculation method of the longitudinal lattice girder use more simple beam, continuous beam. In order to further research the calculation theory and applicability of the longitudinal lattice girder structure, making the calculation method reflect the mechanical properties of the longitudinal lattice girder accurately, this paper through the use of ANSYS finite element numerical simulation method[1], and the improved method of Winkler[3], considering the impact of the tangential component of the anchor rod axial force, and considering the impact of excavation conditions of the deep foundation pit actual, compare the calculation results of the internal force of the longitudinal lattice girder, concluded the optimization calculation method of the longitudinal lattice girder and the applicability.

You might also be interested in these eBooks

Advances in Civil Engineering and Architecture Innovation

View Preview

Info:

Periodical:

Advanced Materials Research (Volumes 368-373)

Pages:

1975-1980

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.368-373.1975

Citation:

Cite this paper

Online since:

October 2011

Authors:

Wei Shi, Xia Zhang, Cong Shen

Keywords:

Finite Element, Improved Method of Winkler, Longitudinal Lattice Girder, Numerical Simulation, Optimization Calculation

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] Jing Chen, Guozhong Cai . Computer-Aided Engineering Analysis ANSYS Guide, In Chinese. [M]. Beijing: Chinese Railway Press,2001, 1-2, 104-106.

Google Scholar

[2] Haimin Li, Ruihui Zhong, Xuan Liu. Internal force calculation method of lattice beam in anchor frame beam, In Chinese. [J]. Pre-stressed technique, 2006,(4):7.

DOI: 10.59238/j.pt.2006.04.002

Google Scholar

[3] Jikai Zhou, Qinqing Du. Modified Winkler foundation model with horizontal force taken into account，In Chinese. [J]. Journal of Hehai University.32

Google Scholar
