Finite Element Analysis for Effect of Initial Load on Dynamic Characteristic of Beams

Abstract:

Based on nonlinear elastic theory and Hamilton’s principle, a generalized element stiffness matrix, which incorporates the effects of flexural as well as axial stresses induced by initial load, is given. A finite element method for dynamic analysis considering the effect of initial load is presented, with corresponding computer programs produced to facilitate the analysis. The formula is validated through a comparison in results with the analytical solution. The effects of key physical factors, including the type and magnitude of initial load, and stiffness parameters such as sectional inertia moment, inertia radius and span, on the dynamic characteristics of the beams with various restraint conditions are discussed with the effect of initial flexural stress considered. The results suggest that the natural frequency of the beam would be enhanced due to the existence of flexural stress induced by initial load and such as effect relates to the magnitude of initial load and stiffness parameters of the beam.

• Periodical: Advanced Materials Research (Volumes 368-373)
• Pages: 2031-2040
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.368-373.2031
• Online since: October 2011
• Authors: Jia Wei Zhang, Zhi Guo Yang, Ya Ping Wu, Shi Jun Zhou, Jian Chang Zhao
• Keywords: Dynamic Characteristic, Finite Element Method (FEM), Hamilton’s Principle, Initial Load, Load-Influenced Stiffness Matrix

References

[1] Zhang Xiaomin, Zhang Peiyuan, Peng Xianghe, Problems of small deformation on pre-stressed configuration [J]. Engineering Me- chanics, 2003,20(3): 125-128.(in Chinese)

[2] Chandrasekaran, A.R. (1969). "Live load effect of dynamic response of structures." J.Struct. Div., ASCE, 95(4),649-660.

DOI: 10.1061/jsdeag.0002243

[3] Zhou, S.J. (1991). "A thin-walled box box beam element and tis applications in structural analysis." Proc., Third East Asia-Pacific Conf. on Struct. Engrg. And Constr., Shanghai, China, Vol.1, 127-132.

[4] H. Takabatake. Effects of dead loads on natural frequencies of beams [J]. Journal of Structural Engineering ASCE, 1991, 117(4): 1102-1120.

[5] Zhang Jiawei, Zhou Shijun. Analysis of effect of dead loads on natural frequencies of arch beams[J]. Journal of Vibration and Shock, 2009,28(8): 163-167.(in Chinese)

[6] Zhou Shijun, Zhang Jiawei. Analysis of the effect of dead loads on static arch beams[J]. Engineering Mechanics, 2010,27(7):120-125.(in Chinese)

[7] Zhang Jiawei, Zhou Shijun. Approximate solutions of static arch beams considering dead loads effect[J]. Chinese Journal of Computational Mechanics, 2010,27(4):665-660.(in Chinese))

[8] Zhou Shijun, Zhu Xi. Analysis of Effect of Dead Loads on Natural Frequencies of Beams [J]. Journal of the China Railway Society, 1995,17(4)：98-103. (in Chinese)

[9] Zhu Xi, Zhou Shijun. A Finite Element Method for Analyzing the Effect of Dead Loads[J]. Engineering Mechanics, 1996,13(3): 54-60.(in Chinese)

[10] Zhou S J, Zhu X. Analysis of Effect of Dead Loads on Natural Frequencies of Beams Using Finite Element Techniques. Journal of Structural Engineering, ASCE, 1996, 122 (5) : 512-516.

DOI: 10.1061/(asce)0733-9445(1996)122:5(512)

[11] Zhou Shijun. Stiffness Method for Non-linear Analysis of Effect of Dead Loads on Plates[J]. Journal of Vibration and Shock, 2007,26(2):33-36.(in Chinese)

[12] Washizu, K. (1982). Variational methods in elasticity and plasticity, 3rd Ed., Pergamon Press, New York, N.Y.
