Analysis of Dynamic Displacement Response of Bridge with Impact of Standard Energy

Abstract:

Conventional method is getting static displacement calculated by dynamic displacement and impact coefficient aim at making the detection of the bridge faster and more precise. But in fact, it is too difficult to ensure the dynamic displacement under the influence of roughness of the bridge deck. For the reasons given above, this paper simulates the bumping testing on the cross section of midspan by explicit dynamic FEM. A vehicle passes through the cross tie which is higher than the highest unevenness, and then gives an impact load to the cross section of the midspan for getting the maximum dynamic displacement of the cross section. This method can eliminate the influence of roughness of the bridge deck and it is a new pathway of bridge dynamic testing.

• Periodical: Advanced Materials Research (Volumes 368-373)
• Pages: 2132-2135
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.368-373.2132
• Online since: October 2011
• Authors: Xian Min Zhang, Ke Shi Xu
• Keywords: Bridge Mechanical Properties, Coefficient of the Impact, Dynamic Displacement, Impact of the Standard Energy, Roughness of the Bridge Deck

References

[1] Zengguo Jiang, Weilian Qu, Shangqing Xing and Jin Zhang: Journal of Wuhan University of Technology. Vol. 24(2002), P.57

[2] Shudong Wang, Jianqing Bu, Guochong Lou: Journal of Chang' an University ( Natural Science Edition), Vol. 28(2008), P. 63

[3] Xinhua Wan, Xiaoyao Hu, Hongping Hao, Hongping Zhu: Journal of Vibration and Shock, Vol. 26(2007), P. 66

[4] Ying Shi, Jiming Xuan, Yifan Song:  Bridge Construction, Vol. 6(2009), P. 15

[5] Yongchun Cheng, Guojin Tan, Hanbin Liu, Fushou Liu: Journal of Virbration Engineering, Vol. 22(2009), P. 474
