Research on the Design of Linear Drive Motor of New Pumping Unit

Abstract:

The new energy saving pumping unit driven by linear induction motor (LIM) not only can overcome many disadvantages of traditional beam-pumping unit, but also has a lot of advantages, such as reliability, high operating efficiency, etc. So it arouses the universal concern of the oil industry. This paper focuses on the study of linear motor. Firstly, it analyzes the advantages of the pumping unit driven by LIM relative to beam-pumping unit, then in accordance with the system design requirements and based on the electromagnetic design method of linear motor, makes the theoretical calculation and the structure design of the motor, determines specific parameters of LIM, produces LIM applicable to the practical application to drive pumping unit. Lastly, makes field experiments, and experiments results show that LIM has reached the design requirements, also verify the correctness and feasibility of the design method.

• Periodical: Advanced Materials Research (Volumes 383-390)
• Pages: 1391-1398
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.383-390.1391
• Online since: November 2011
• Authors: Wen Zhong Ma, Hong Mei Zhang, Jin Yan Sun, De Bao Tian, Hong Fei Pang
• Keywords: Control, LIM, Parameter, Structure

References

[1] Xiangcheng Guo, Basic Research on Brushless DC Linear Motor of Electromagnetic Pumping Unit, (In Chinese). Harbin: Harbin Institute of Technology, 2006, pp.1-3.

[2] Koepfer C, Linear Motor Drives-A Fast Track for Machine Tools,. Machine Shop. Vol. 1, 1994, pp.64-70.

[3] Minzheng Jiang, Jianping Wang, Xuefeng Zheng, Jinrong Liu, Huifeng Sun, Deshi Zhang, Study of linear electric motor driving pumping unit,. OIL FIELD EQUIPMENT (In Chinese). Vol. 35, 2006, pp.38-41.

[4] Lianfeng Zhao, Kuisheng Wang, Geng Luo, Kai Luo, The design of ZDCYJ-I pumping unit driven by a linear motor,. OIL FIELD EQUIPMENT (In Chinese). Vol. 34, 2005, pp.42-44.

[5] Weixin Wu, Research on the Key Components of New Pumping Unit, (In Chinese). Nanjing: Nanjing University of Science and Technology, 2006, pp.23-32.

[6] Idir K, Dawson G E, Easthan A R. Modeling and performance of linear induction motor with saturable primary,. IEEE Trans. On Industry Applications, vol. 29, 1993, pp.1123-1128.

DOI: 10.1109/28.259722

[7] Yunyue Ye, Linear Motor Principle and Application, (In Chinese). Beijing: Mechanical Industry Press, 2004, pp.1-24.

[8] Robert Aronson. Attact of the Linear Motors,. Manufacturing Engineering. Vol. 5, 2005, pp.60-70.
