Research and Analyze on the Lightning Test of Aircraft Model

Abstract:

According to the China Aviation Industry Standard HB6129 “The requirements of aircraft lightning protection and test method” and standards of foreign countries. The high voltage generator was used to make the lightning attachment point test on a scale model of airplane. The lightning attachment zone was determined, and the result was agreed with the actual lightning experience of F-4 aircraft. The technical factors such as test method, the model scale, gap spacing, and polar discharge relative positions in respect to the model are related to the laboratory test; the lightning discharging theory will be discussed in detail. The test method has been proved feasible and the experience of test research work has accumulated for future use.

• Periodical: Advanced Materials Research (Volumes 383-390)
• Pages: 2361-2365
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.383-390.2361
• Online since: November 2011
• Authors: Hao Wen, Hong Wang
• Keywords: Attachment Point, High Voltage Generator, Lightning, Scale Model

References

[1] Yu hao, Technical basis of modern lightning protection（Second Edition）, Tsinghua University Press, (2005).

[2] Guang xiangshan, Wang fengshan, et al., The lightning destructive accidents collection of our country and other countries, Meteorology Press, (1997).

[3] B. D. Fisher, P. W. Brown and J, A. Plumer, Summary of NASA Storm Hazards Lightning Research, 1980-1985, 1986 International Aerospace and Ground Conference on Lightning and Static Electricity, Oct. 1986. Paper 4.

[4] J.R. Stahmann, Triggered natural lightning near an F-100 aircraft, , Lightning and Static Electricity Conference, Dec. 1968. pp.123-134.

[5] Eberle, M., Marcordes, R., Jaeger, D., Perala, R., Plumer, A., Schwartz, H. Lightning Protection Design Methodology for a Very large Non-Rigid Airship, International Conference on Lightning and Static Electricity Conference Paper 2001-01-2931, Society of Automotive Engineers, Inc. (2001).

DOI: 10.4271/2001-01-2931

[6] Major James M. Gruden, et al., Analysis of simulated ai rcraft lightning strikes and there electromagnetic effects", AFRL-PR-WP-TR-2001-2024, Feb. (2001).

[7] D.W. Chifford, Laboratory tests to determine lightning attachment points with small aircraft models, (Engineering Test) Conference on Certification of aircraft for Lightning and Atmospheric Electricity Hazards, Sept. 1978. paper. 9.

[8] D.W. Chifford, Scale model lightning attach point testing, , Lightning and Static Electricity Conference, April (1975).

[9] M. A. Uman, Natural artificially-initiated lightning and lightning test standards, Proceedings of the IEEE, vol. 76, No. 12, p.1548–1565, Dec. (1988).

DOI: 10.1109/5.16349

[10] P.F. little, Laboratory tests to determine lightning attachment points with small aircraft models, (Engineering Test) Conference on Certification of aircraft for Lightning and Atmospheric Electricity Hazards, Sept. 1978. paper. 8.

[11] MIL-STD-464. Electromagnetic environment effects requirements for systems [S]. (1997).

[12] MIL-STD-1757 Lightning qualification test techniques for aerospace vehicles and hardware [S]. (1980).

[13] MIL-STD-1795 Lightning Protection of Aerospace Vehicles and Hardware [S]. (1989).

[14] HB-6129 The requirements and test methods of aircraft lightning protection. [S]. (1987).

[15] GJB-2639 lightning protection of Military aircraft. [S]. (1996).
