Study and Simulation for MPPT Control of Photovoltaic Generation System Based on Combining Constant Voltage Method with Adaptive Duty Cycle Perturb Method

Abstract:

A MPPT (Maximum Power Point Tracking) control method of PV (Photovoltaic) generation system is proposed based on the shortcoming of the existing MPPT algorithms. The method applies CVT (Constant Voltage Tracking) algorithm to adjust the working point of PV array near the MPP (Maximum Power Point) for fast tracking when working point is far from MPP, and uses adapting duty cycle perturb method to optimize the steady state characteristic of MPP for effectively eliminate the output power oscillation under the setting precision. Its model is established and simulated with Matlab/Simulink.The CVT, duty cycle method and proposed methods are simulated respectively and simulation results show that, the proposed method tracks the MPP exactly and quickly and improves the energy conversion efficiency of PV generation system by eliminate the output power oscillation around MPP. Its fast response speed improves the static and dynamic performance of photovoltaic power system.

• Periodical: Advanced Materials Research (Volumes 383-390)
• Pages: 2590-2595
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.383-390.2590
• Online since: November 2011
• Authors: Wang Dong Yun, Xu Qi Ying, Zhu Yong Sheng, Xiao Jun Ming, Hu Jiang Xue
• Keywords: Adaptive Duty Cycle Perturb Method, Constant Voltage Method, MPPT, Photovoltaic Generation System

References

[1] B. K. Bose, P. M. Szczesny, and R. L. Steigerwald, Microcomputer control of a residential power conditioning system, IEEE Trans. Ind. Applicat, vol. IA-21, p.1182–1191, Sept. /Oct. (1985).

DOI: 10.1109/tia.1985.349522

[2] Walker G, Evaluating MPPT converter topologies using a Matlab PV model, J Elect Electron Eng, vol. 21, pp.49-56, (2001).

[3] Xiong Yuansheng, Yu Li, Xu Jianming, MPPT control of photovoltaic generation system combining constant voltage method with perturb-observe method, Electric Power Automation Equipment, vol. 29, pp.85-88, (2009).

[4] Qiao Xinghong, Wu Bijun, Deng Zangao, You Yage, MPPT of photovoltaic generation system using fuzzy/PID control, Electric Power Automation Equipment, vol. 28, pp.92-95, (2008).

[5] Pandey A, Dasgupta N, Mukerjee A K, A simple single-sensor MPPT solution, IEEE Transaction on Power Electronics, vol. 22, pp.698-700, (2007).

DOI: 10.1109/tpel.2007.892346

[6] LI Qiuhua, Zhou Lin, Liu Qiang, Zhang Feng, Wu Jian, Simulative research of MPPT for photovoltaic power system, Electric Power Automation Equipment, vol. 28, pp.21-25, (2008).

[7] Chen Y K, Yang C H, Wu Y C, Robust fuzzy controlled photovoltaic power inverter with Taguchi method, IEEE Transaction on Aerospace and Electronic Systems, vol. 38, pp.940-954, (2002).

DOI: 10.1109/taes.2002.1039410

[8] Cheng qi-ming, Cheng yi-man, Wang ming-mei, Ni ren-jie, Review on the MPPT method of PV battery, East China Electric Power, vol. 37, pp.1300-1305, (2009).

[9] Koutroulis E, Kalaitzakis K, Voulgaris N C, Development of a microcontroller-based, photovoltaic maximum power point tracking control system, IEEE Transaction on Power Electronics, vol. 16, pp.46-52, (2001).

DOI: 10.1109/63.903988

[10] C. Alippi, C. Galperti, An adaptive maximum power point tracker for maximizing solar cell efficiency in wireless sensor nodes, Proc. ISCAS 2006, Kos, Greece, pp: 3722-3725, May (2006).

DOI: 10.1109/iscas.2006.1693436
