Effects of Speed Ratio K Value of Rubber-Bar on Cotton Harvesting Performance

Abstract:

Structure, cotton harvesting principal and main working parameters of rubber-bar roller harvester were studied in this paper. K value of rubber-bar roller speed ratio was determined based on displacement and velocity equations of rubber-bar end established by work pattern of the roller. The functional relationship between K value and harvest angle β of cotton plant by rubber-bar was derived. Additional, t Additional, the effects of K value on angle β and cotton harvesting performance were analyzed. The experimental results showed that collect rate of cotton was above 95% and percentage of impurities was less than 18% when working speed was 3 km•h^-1 and K value ranged between 6.8～8.3.

• Periodical: Advanced Materials Research (Volumes 383-390)
• Pages: 3005-3010
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.383-390.3005
• Online since: November 2011
• Authors: Hong Wen Zhang, Min Kang
• Keywords: Cotton Harvesting Performance, Harvest Angle β, K Value, Rubber Bar Harvester

References

[1] J. Mei, The Processing Technology of Cotton for Mechanized Harvesting, China Cotton Processing, p.35–36, Feb 2002. (in Chinese).

[2] China Institute of Scientific Research of Agricultural Mechanization, Agricultural Machinery Design Manual (part 1), Beijing: China Agricultural Science and Technology Press, 2007. (in Chinese).

[3] China Institute of Scientific Research of Agricultural Mechanization, Translation Collection of Cotton Harvester, Beijing: China Mechanical Industry Press, 2007. (in Chinese).

[4] J. C. Faircloth, R. Hutchinson, J. Barnett, An Evaluation of Alternative Cotton Harvesting Methods in Northeast Louisiana A Comparison of the Brush Stripper and Spindle Harvester, The Journal of Cotton Science, 2004, vol. 8, p.55–61.

[5] A. D. Brashears, R.V. Baker, Comparison of Finger Strippers, Brush Roll Strippers and Spindle Harvesters on The Texas High Plains, In Proc. Beltwide Cotton Conf. San Antonio, TX. 4-8 Jan 2000, pp.452-453.

[6] Agricultural Bureau of Production and Construction corps in Xinjiang, Working Technical Regulations of Cotton Harvester, Xinjiang Agricultural Mechanization, pp.20-21, May 2005, (5). (in Chinese).

[7] Q. S. Wei. Extension and Matching Technology of Cotton for Mechanized Harvesting, China Cotton, p.26, Dec 2006. (in Chinese).

[8] National Standrad, Cotton harvesters, GB/T 21397-2008 (in Chinese).

[9] National Standrad, Test method for percentage of trash, GB/T 6499-2007. (in Chinese).

[10] Standrad of Department of Agriculture Operating quality for cotton picker, NY/ T 1133－2006. (in Chinese).
