Research of Roll-Isolated Gimbal Platform and a Two-Position Initial Alignment Scheme of SINS in Spinning Projectile

Abstract:

It is difficult to apply a traditional strapdown inertial navigation system(SINS) to spinning projectile because of high spin rate. A Roll-Isolated gimbal platform is introduced to prevent SINS by the projectile’s spinning motion. Roll-Isolation is accomplished by supporting the inertial measurement unit(IMU) on a single gimbal, the axis of which is parallel to the projectile’s spinning axis. Roll-Isolation prevents the saturation of the roll gyro by the high vehicle spin rate and greatly reduces the measurement errors arising from gyro scale factor and misalignment. On the basis of roll-isolation, the paper presents a Two-Position initial alignment scheme of SINS on stationary base, which is realized by changing the IMU roll angle around the spinning axis. Furthermore, the paper studies on the observability of the scheme, and the results show that it not only improves observability but also minimizes alignment errors.

• Periodical: Advanced Materials Research (Volumes 383-390)
• Pages: 4115-4120
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.383-390.4115
• Online since: November 2011
• Authors: Yong Sheng Shi, Bo Wang, Ming Jie Dong, Zhi Feng Gao
• Keywords: Initial Alignment, SINS, Spinning Projectile

References

[1] Wan Dejun, Fang Jiancheng, Initial Alignment of Inertial Navigation, Nanjing: Southeast University Press, Dec. (1998).

[2] Zhou Qi, Qin Yongyuan, Zhao Changshan, Design on stabilization loop of roll-isolated SINS in spinning projectile, Journal of Chinese Inertial Technology, vol. 17 No. 4, Aug. 2009, p.383: 387.

[3] Mark E. Beader, Application of Roll-isolated inertial Measurement Units to the Instrumentation of Spinning Vehicles. Sandia Report, Sandia national laboratory, (2000).

DOI: 10.2172/772048

[4] Yang Yanjuan, Huang Deming, Wang Hui, Application of optimal two-position alignment in SINS self-alignment, Journal of projectiles Rockets Missiles and Guidance, vol. 21 No. 2, Apr. 2001, p.8: 10.

[5] Yu Jiacheng, Chen Jiabin, Multiposition observability analysis of strapdown inertial navigation system, Journal of Beijing Institute of Technology, vol. 24 No. 2, Feb. 2004, p.150: 153.

[6] Goshen-Meskin D, Bar-Itzhack I. Y, Observability analysis of piece-wise constant systems-part I: theory, IEEE Transaction on Aerspace and Electronic systems, vol. 28, No. 4, oct. 1992, p.1056: 1068.

DOI: 10.1109/7.165367
