Second Order Sliding Mode Control of Direct-Drive Ring Permanent Magnet Torque Motor

Abstract:

The direct-drive ring permanent magnet torque motor is easily affected by parameters changes and the load torque disturbances, which reduces the servo performance of the system. In order to enhance the robustness of the servo system, the super twisting algorithm based on the second order sliding mode control (SMC) is proposed as the speed controller of the direct-drive servo system. The super twisting algorithm need not know the information of the sliding mode time derivative, which through the continuous control measure the sliding mode and its derivative approach zero in finite time. This method not only guarantees the robustness of the servo system and eliminates chatting, but also enhances the static precision of the servo system. The simulation results show that the servo system of the direct-drive NC rotary table has a very strong robustness by adopting the control method against parameters changes and the external disturbances.

• Periodical: Advanced Materials Research (Volumes 383-390)
• Pages: 5964-5971
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.383-390.5964
• Online since: November 2011
• Authors: Yi Biao Sun, Ya Nan Jing, Jia Kuan Xia
• Keywords: Direct Drive, Permanent Magnet Ring Torque Motor, Second Order Sliding Mode Control, Super Twisting Algorithm

References

[1] Chengyuan Wang, Jiakuan Xia, Junyou Yang. The Modern Control Technology of the Motor, Beijing, China machine press, (2006).

[2] Jing Ke, Ming Zeng, Baoku Sun. Disturbance Torque Compensation for Brushless DC Motors via Adaptive Control, Journal of Chinese Inertial Technology, vol. 10, 2002, pp.68-71.

[3] Yibiao Sun, Qiujin Wei, Chengyuan Wang. Discrete-time Second-order Sliding Mode Control for Permanent-magnet Ring Torque Motor, Modular Machine Tool and Automatic Manufacturing Technique, vol. 3, 2008 , pp.42-45.

DOI: 10.1109/ccdc.2013.6560983

[4] Yibiao Sun, Yan Zhao, Chengyuan Wang. Speed Control for Permanent Magnet Ring Torque Motor Based on Multi-objective Genetic Algorithms, Electrical Engineering, vol. 9, 2008, pp.42-45.

[5] Arie Levant, Member. Chattering Analysis, IEEE Transactions on Automatic Control, vol. 55, 2010, pp.1380-1389.

DOI: 10.1109/tac.2010.2041973

[6] Igor Boiko, Leonid Fridman, Alessandro Pisano. Analysis of Chattering in Systems with Second-order sliding mode, " IEEE Transactions on Automatic Control, vol. 52, 2007, pp.2085-2102.

DOI: 10.1109/tac.2007.908319

[7] Michael Defoort, Thierry Floquet, Annemarie Kokosy et al. A novel higher order sliding mode control scheme., Systems and Control Letters, vol. 58, 2009, pp.102-108.

DOI: 10.1016/j.sysconle.2008.09.004

[8] Alberto Cavallo, Ciro Natale. Second order Sliding Mode Output Control of Permanent Magnet Synchronous Machines, IEEE Conference on Decision and Control and 28th Chinese Control Conference, (2009).

DOI: 10.1109/cdc.2009.5400935

[9] Brice Beltran, Tarek Ahmed-Ali, Mohamed EI Hachemi Benbouzid. Higher-Order Sliding-Mode Control of Variable-speed Wind Turbines, IEEE Transactions on Automatic Control, vol. 56, 2009, pp.3314-3321.

DOI: 10.1109/tie.2008.2006949

[10] Jing Wang, Qiming Zeng, Design of Second order Sliding Mode Controller for Synchronous Generators based on Singular Perturbation, Proceedings of the CSEE, vol. 23, 2003, pp.142-147.

DOI: 10.1109/icpst.2002.1053560

[11] Yibiao Sun, Xue Yang, Jiakuan Xia. Second Order Sliding Mode Control for PMSM Using Robust Differentiator, Proceedings of the CSEE, vol. 27, 2007, pp.6-10.
