Pressure Forecast of an Air-Cooled Steam Condenser under Wind Speeds

Abstract:

Direct air-cooled power plant is popularized in north China because of the water conservation. Different from the water-cooled condenser, the ambient air absorbs the latent heat that turbine exhaust in the heat exchangers releases. In this paper, the numerical model of a 2×600MW power plant is prepared to simulate the performance of the air–cooled steam condenser under different wind speeds. Heat transferring with phase change is very complicated so that User Define Function(UDF) is applied to calculate the heat transfer rate in the air-cooled condenser. The fan flow rate will drop obviously during the increasing of the wind speed. As a result, the heat transfer rate between the steam and the ambient air also decreases and the pressure of the condenser rises. Finally, the stable condenser pressures under different wind speeds are predicted. The result shows that the air-cooled condenser is very sensitive to the wind speed.

• Periodical: Advanced Materials Research (Volumes 383-390)
• Pages: 6187-6193
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.383-390.6187
• Online since: November 2011
• Authors: Wei Feng He, Yi Ping Dai
• Keywords: Air-Cooled Steam Condenser, Condenser Pressure, Latent Heat, Numerical Model, Water Conservation, Wind Speed

References

[1] Gu, Z.F., Chen, X.R., William Lubitz, Li, Y., Luo, W.L. Wind tunnel simulation of exhaust recirculation in an air-cooling system at a large power plant. International Journal of Thermal Sciences 46 (3), 308-317, (2007).

DOI: 10.1016/j.ijthermalsci.2006.04.007

[2] Liu, P.Q., Duan, H.S., Zhao, W.L. Numerical investigation of hot air recirculation of air-cooled condensers at a large power plant. Applied Thermal Engineering 29 (10), 1927-1934, (2009).

DOI: 10.1016/j.applthermaleng.2008.09.011

[3] Stinnes, W.H., von Backstrom, T.W. Effect of cross-flow on the performance of air-cooled heat exchanger fans. Applied Thermal Engineering 22 (12), 1403-1415, (2002).

DOI: 10.1016/s1359-4311(02)00060-1

[4] Salta, C.A., Kroger, D.G. Effect of inlet flow distortions on fan performance in forced draft air–cooled heat exchangers. Heat Recovery Systems & CHP 15 (6), 555-561, (1995).

DOI: 10.1016/0890-4332(95)90065-9

[5] Thiart, G.D., von Backstrom, T.W. Numerical simulation of the flow field near an axial flow fan operating under distorted inflow conditions. Journal of Wind Engineering and Industrial Aerodynamics 22 (12), 189-214, (1993).

DOI: 10.1016/0167-6105(93)90270-x

[6] Meyer, C.J., Kroger, D.G. Air-cooled heat exchanger inlet flow losses. Applied Thermal Engineering 21 (7), 771-786, (2001).

DOI: 10.1016/s1359-4311(00)00083-1

[7] Bredell, J.R., Kroger, D.G., Thiart, G.D. Numerical investigation of fan performance in a forced draft air-cooled steam condenser, Applied Thermal Engineering 26 (8-9), 846-852, (2006).

DOI: 10.1016/j.applthermaleng.2005.09.020

[8] Meyer, C.J., Kroger, D.G. Plenum chamber flow losses in forced draught air-cooled heat exchangers. Applied Thermal Engineering 18 (9-10), 875-893, (1998).

DOI: 10.1016/s1359-4311(97)00109-9

[9] van Rooyen, J.A., Kroger, D.G. Performance Trends of an Air-Cooled Steam Condenser Under Windy Conditions. J. Eng. Gas Turbines Power 130 (2), (2008).

DOI: 10.1115/1.2771567

[10] Weifeng, He. Research on the Influence of Ambient Wind Speed to the Operation Performance of Direct Air-Cooled Power Plant. Xi'an Jiaotong University, Xi'an, (2009).

[11] Wang, F.J. Computational Fluid Dynamics Analysis. Tsinghua University Press, Beijing(in Chinese), (2004).
