Laser Welding Simulations of Stainless Steel Joints Using Finite Element Analysis

Abstract:

Laser beam welding (LBW) is a fusion joining process that uses the energy from a laser beam to melt and subsequently crystallize a metal, resulting in a bond between parts. In this study, finite element method (FEM) is used for predicting the weld bead profile of laser welding butt, lap and T-joints. A three-dimensional finite element model is used to analyze the temperature distribution weld bead shape for different weld configurations produced by the laser welding process. In the model temperature-dependent thermo physical properties of AISI304 stainless steel, effect of latent heat of fusion and convective and radiative boundary conditions are incorporated. The heat input to the FEM model is assumed to be a 3D conical Gaussian heat source. The finite element software SYSWELD is employed to obtain the numerical results. The computed weld bead profiles for butt, lap and T-joints are compared with the experimental profiles and are found to be in agreement.

• Periodical: Advanced Materials Research (Volumes 383-390)
• Pages: 6225-6230
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.383-390.6225
• Online since: November 2011
• Authors: K.R. Balasubramanian, T. Suthakar, K. Sankaranarayanasamy, G. Buvanashekaran
• Keywords: Finite Element Analysis (FEA), Laser Welding, Simulation, Stainless Steel (SS), SYSWELD

References

[1] Steen, W.M. Laser material processing, Third Edition, Springer, (2003), pp.157-196.

[2] Du H, Hu L, Liu J and Hu X, A study on the metal flow in full penetration laser beam welding for titanium alloy, Computational Materials Science Vol. 29 (2004), p.419–427.

DOI: 10.1016/j.commatsci.2003.11.002

[3] Siva Shanmugam N, Buvanashekaran G, Sankaranarayanasamy K and Ramesh Kumar S, A transient finite element simulation of the temperature and bead profiles of T-joint laser welds, Materials and Design Vol. 31 (2010), p.4528–4542.

DOI: 10.1016/j.matdes.2010.03.057

[4] Tsirkas SA, Papanikos P, Kermanidis Th. Numerical simulation of the laser welding process in butt-joint specimens. J Mater Process Technol Vol. 134 (2003), p.59–69.

DOI: 10.1016/s0924-0136(02)00921-4

[5] Chang WS, Na SJ. Prediction of laser spot welds shape by numerical analysis and neural network. Metall Mater Trans B Vol. 32B (2001), p.723–31.

[6] Frewin MR, Scott DA, Finite element model of pulsed laser welding Weld J Vol. 78 (1999), p. 15s–22s.

[7] Balasubramanian KR, Siva Shanmugam N, Buvanashekaran G, Sankaranarayanasamy K. Numerical and experimental investigation of laser beam welding of AISI 304 stainless steel sheet, Adv Prod Eng Manage J Vol. 3 (2008), p.93–105.

DOI: 10.1111/j.1747-1567.2009.00552.x

[8] SYSWELD, Reference manual (2007), ESI-Group.
