Design and Rapid Manufacturing Structural Components of a Mini-Scale Underwater Vehicle

Abstract:

Underwater vehicles have been developed mainly for underwater exploration and rescue. Many large- and middle-size vehicles are available but few are in smaller scale. As the size goes into mini-scale which is less than 20 cm, it is challenging to allocate required components within limited space, while providing designed functions at the same time. The aims of this research are to design and rapid manufacture structural components for a remote-controlled underwater vehicle in the mini-scale region. The vehicle would integrate vision capability to provide functions of underwater ecological observation and tracking. In order to design the structural components for this mini-scale vehicle, commercial CFD software was adopted to simulate flows. An improved external shape was obtained and detailed designs of the structural components were implemented. A rapid prototyping technique, Shape Deposition Manufacturing (SDM) process, was utilized to rapidly manufacture these components. The finished components were assembled with control modules and propulsion systems as an underwater vehicle and the preliminary underwater test was conducted successfully.

• Periodical: Advanced Materials Research (Volumes 383-390)
• Pages: 6352-6356
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.383-390.6352
• Online since: November 2011
• Authors: Yih Lin Cheng, Rui Dong Chang
• Keywords: Layered Manufacturing (LM), Shape Deposition Manufacturing (SDM), Underwater Vehicle

References

[1] P. G Collar and S.D. McPhail: IEE Electronics & Communication Engineering Journal, Vol. 7, No. 3 (1995), pp.105-114.

[2] Information on AUV Lab Vehicles, AUV Lab at MIT Sea Grant (http: /auvlab. mit. edu/vehicles/).

[3] B. Hobson, B. Schulz, J. Janet, M. Kemp, R. Moody , C. Pell, H. Pinnix: Develoment of a Micro Autonomous Underwater Vehicle For Complex 3-D Sensing, IEEE Conference and Exhibition, Vol. 4 (2001).

DOI: 10.1109/oceans.2001.968311

[4] S.B. Williams and I. Mahon: Design of an unmanned underwater vehicle for reef surveying, Proceedings of IFAC 3rd IFAC Symposium on Mechatronic Systems (2004).

DOI: 10.1016/s1474-6670(17)31100-x

[5] P. Walters, D. Hughes, T.P. Feeney, S. Nayak, N. Fischer, G. Dash, E.M. Schwartz, A.A. Arroyo: SubjuGator 2010, Florida Conference on Recent Advances in Robotics, FCRAR 2010 (2010).

[6] R. Merz, F.B. Prinz, K. Ramaswami, M. Terk, L. Weiss: Shape Deposition Manufacturing, Proceedings of the Solid Freeform Fabrication Symposium (1994), pp.1-8.

[7] Y. -L. Cheng and J. -H. Lai: Journal of Materials Processing Technology, Vol. 201 (2008), pp.640-644.
